Zone Valve, 3 Way, Open System, 1/2 In NPT - V050T3G1ZA024Q4A2
TacoLog in for pricing
(No reviews yet)
Write a Review
Taco
Zone Valve, 3 Way, Open System, 1/2 In NPT - V050T3G1ZA024Q4A2
Motorized Zone Valve, Actuator Control Pressure - Maximum Not Applicable, Actuator Control Pressure - Minimum Not Applicable, Actuator Control Signal On/Off, Actuator Return Action Double Acting, Actuator Type Electric, Actuator Voltage 24V AC, Allowable Pressure - Maximum 300 psi, Application Geothermal, Body Material Brass, Body Pattern Three-Way, Bypass Port Coefficient of Volume (Cv) 1.5, Close-Off Pressure 125 psi, Coefficient of Volume (Cv) 4.9, Fluid Temperature - Maximum 220 Degrees F
- Country of Origin:
- United States
- Item:
- Motorized Zone Valve
- Body Material:
- Brass
- Voltage:
- 24
- For Use With:
- Geothermal Systems
- Electrical Connections:
- 2-Pin Screw Connectors for Power and End Switch
- Depth (In.):
- 2 3/8 in
- Max. Water Temp. (Deg. F):
- 220 Degrees F
- Type:
- Three Way, Geothermal System
- Connection Type/Size (In.):
- NPT 1/2
- Includes:
- End Switch
- Safe Working Water PSI:
- 300 psi
- Height (In.):
- 5 1/8 in
- Width (In.):
- 5 5/16 in
- Coefficient of Volume:
- 1.5
- Actuator Control Signal:
- On/Off
- Fluid Temperature - Maximum:
- 220 Degrees F
- Actuator Control Pressure - Minimum:
- Not Applicable
- Spring Action:
- Non-Spring Return
- Bypass Port Coefficient of Volume (Cv):
- 1.5
- Stem Material:
- Brass
- Close-Off Pressure:
- 125 psi
- Overall Width:
- 5 5/16 in
- Port Connection Size:
- 1/2 in
- Valve Type:
- Ball
- For Media:
- Steam, Water, Water-Ethanol Solution to 25%, Water-Glycol Solution to 50%, Water-Methanol Solution to 25%
- Coefficient of Volume (Cv):
- 4.9
- Gasket/Plug Material:
- EPDM
- Port Connection Type:
- NPT
- Overall Depth:
- 2 3/8 in
- Body Pattern:
- Three-Way
- Overall Length:
- 5 1/8 in
- Installation Orientation:
- Versatile
- Port Connection Gender:
- Female
- Actuator Control Pressure - Maximum:
- Not Applicable
- Application:
- Geothermal
- Operating Temperature - Maximum:
- 220 Degrees F
- Fluid Temperature - Minimum:
- 20 Degrees F
- Actuator Type:
- Electric
- Actuator Return Action:
- Double Acting
- Allowable Pressure - Maximum:
- 300 psi
- Includes Actuator:
- Actuator Included
- Valve Action:
- Normally Closed
- Actuator Voltage:
- 24V AC
- Package Quantity:
- 1
-
-
