Y-Check Valve, 3/4", PVC/FPM, Socket - YC10075S

Y-Check Valve, 3/4", PVC/FPM, Socket - YC10075S

Hayward Flow Control
SKU:
YC10075S
|
UPC:
610377168533
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Y, Body Material - Valves PVC, Pipe or Tube Size 3/4 in, Connection Type Socket x Socket, Cracking Pressure 1 psi, Mounting Orientation Horizontal, Vertical, Seal Material FPM, Max. Temp. - Valves 140 Degrees F, Min. Temp. - Valves 40 Degrees F, Max. Water Pressure - Valves 150 psi @ 70 Degrees F, Max. Steam Pressure - Valves Not Rated, Seat Material FPM, Flow - Valves 3 gpm, Full Flow - Valves Yes
Additional Information
Country of Origin:
United States
Pipe Size:
3/4";Hex Size=1 1/4""
Connection Type:
socket
Connection:
Socket
Body Material:
PVC
Flow:
3 gpm
Full Flow - Valves:
Yes
Body Material - Valves:
PVC
Flow - Valves:
3.00 gpm
Min. Temp. - Valves:
40 Degrees F
Seat Material - Check Valves:
FPM
Length:
4-3/16";Max. Steam Pressure - Valves=Not Rated"
Mechanism and Body Design:
Y
Seat Material:
FPM
Max. Water Pressure - Valves:
150 psi @ 70 Degrees F
Mounting Position:
Vertical or Horizontal
Seal Material:
FPM
Item - Check Valves:
Check Valve
Cracking Pressure - Check Valves:
1.000 psi
Item:
Y Check Valve
Size:
3/4";Seal Material - Check Valves=FPM"
Max. Temp. - Valves:
140 Degrees F
Max. Water Pressure:
150 psi @ 70 Degrees F
Application - Valves:
General Purpose
Material of Construction:
PVC
Width:
1-11/16";Flow Design=Single"
Cap to Inlet Center:
2-29/32";Mounting Orientation - Check Valves=Horizontal, Vertical"
Cracking Pressure:
1 psi
Overall Height:
3-23/32";Pipe or Tube Size - Check Valves=3/4""
Sub-Category:
PVC
Max. Temp.:
140 Degrees F
Connection Type - Check Valves:
Socket x Socket
Overall Length:
7.42 in
Standards:
ASTM D1784
Spring Material:
Not Applicable
Pipe or Tube Size:
3/4 in
Mounting Orientation:
Horizontal, Vertical
Seal:
FPM
3-A Standard Compliance:
Not Rated
Connection Size - Side 2:
3/4 in
Maximum Pressure - Operating:
150 psi
Coefficient of Volume (Cv):
3
Includes Counterweight:
No Counterweight
Operating Temperature - Maximum:
140 Degrees F
Height - Cap to Inlet Center:
2 7/8 in
Valve Body Style:
Y-Style
Silent Check:
Standard
Connection Type - Side 1:
Socket
Connection Type - Side 2:
Socket
Vacuum Service Rating:
Not Rated
Operating Temperature - Minimum:
34 Degrees F
Manufacturer Warranty:
3 yr
Nominal Valve Size:
3/4 in
Check Mechanism:
Piston
Connection Gender - Side 1:
Female
Connection Size - Side 1:
3/4 in
ANSI Flange Class:
Not Applicable
Connection Gender - Side 2:
Female
For Media:
Water
Average Surface Roughness (Ra):
Not Applicable
Check Mechanism Material:
PVC
Maximum Pressure - Steam:
Not Rated
Package Quantity:
1
