Washdown Motor, 3 Ph, TEFC, 3 HP, 1765 rpm - 5XAU5BG

Name: Washdown Motor, 3 Ph, TEFC, 3 HP, 1765 rpm - 5XAU5BG
Brand: Dayton
SKU: 5XAU5BG
Price: 1950.39 USD
Availability: InStock

Dayton

SKU:

5XAU5BG

UPC:

190735355572

Availability:

In Stock

(No reviews yet)

Washdown Motor, Three Phase, Motor Design 3-Phase, 3 HP, Nameplate RPM 1,765, Voltage 230/460V AC, Full Load Amps 7.6/3.8 A, 182TC Frame, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan-Cooled, Motor Mounting Type Face, Motor Mounting Position Horizontal, Motor Frame Material Epoxy Coated Rolled Steel

Country of Origin:: Mexico
Item:: Washdown Motor
Motor Design:: 3-Phase
Phase:: Three
HP:: 3
RPM Range:: 1,701-1,800
Voltage:: 230/460V AC
Frame:: 182TC
Motor Frame Material:: Epoxy Coated Rolled Steel
Motor Thermal Protection:: None
Motor Enclosure Design:: Totally Enclosed Fan-Cooled
Length Less Shaft:: 14 1/8 in
Max. Ambient Temp.:: 40 Degrees C
Motor Shaft Design:: Keyed
Nominal Efficiency:: 89.5 %
Standards:: CSA Certified (258525), UL Recognized (E47479), USDA Approved
Duty:: Continuous
Shaft Length:: 2 5/8 in
Application:: High Humidity, Wet Environments and Areas Where Motor is Occasionally Exposed to High Pressure Washdowns
Voltage Compatibility:: 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Motor Bearings:: Ball
Shaft Dia.:: 1 1/8 in
Hz:: 60/50 Hz
Motor Shaft Rotation:: CW/CCW
Inverter Rated:: Yes
CC Number:: CC030A
Motor Application:: Washdown
Frame Material:: Epoxy Coated
NEMA Design:: B
Footnotes:: 8, 11, 51
Body Dia.:: 9.13 in
Endshields:: Cast Aluminum
Nameplate RPM:: 1,765
Motor Service Factor:: 1.15
Conduit Box:: Cast Aluminum with Buna-N Gasketed Cover
Full Load Amps:: 7.6/3.8 A
Motor Mounting Position:: Horizontal
Overall Length:: 16 3/4 in
Shaft Material:: 303 Stainless Steel
Ins. Class:: F
Motor Mounting Type:: Face
Drain Plugs:: (4) Shaft End, (4) Lead End, (2) In Conduit Box
Endshield Material:: Cast Aluminum
Duty Cycle:: Continuous
Package Quantity:: 1
