Vacuum Gauge, 30 Hg to 0, 4-1/2In, 1/4In - 45-1082AS 02L VAC

Vacuum Gauge, 30 Hg to 0, 4-1/2In, 1/4In - 45-1082AS 02L VAC

Ashcroft
SKU:
45-1082AS 02L VAC
|
UPC:
723259334145
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Vacuum Gauge, Gauge Type Test, Dial Size (In.) 4-1/2, Range 30" Hg Vac to 0, Connection Size 1/4" NPT, Connection Location Lower, Smallest Graduation (PSI) 0.1, Accuracy (%) +/-0.25, Case Material Epoxy Coated Aluminum, Case Color Black, Socket Material Bronze, Tube Material Bronze, Lens Material Glass, Ring Material Hinged Steel, Operating Temp. Range (F) -40 Degrees to 150 Degrees , Series 1082, Manufacturers Warranty Length 1 Year
Additional Information
Country of Origin:
United States
Pressure and Vacuum Gauge Type:
Vacuum Gauge
Gauge Application:
Test
Liquid Filled:
No
Gauge Nominal Dial Size:
4 1/2 in
Basic Gauge Case Material:
Aluminum
Basic Gauge Wetted Parts:
Bronze
Gauge Connection Type:
MNPT
Gauge Connection Size:
1/4 in
Gauge Connection Location:
Bottom
Gauge Primary Range Units:
in Hg
Gauge Case Color:
Black
Gauge Primary Range Values:
-30 to 0
Gauge Socket Material:
Bronze
Gauge Lens Material:
Glass
Series:
1082
Gauge Sensor Material:
Phosphor Bronze
Item:
Vacuum Test Gauge
Calibration Certificate Included:
No
Gauge Primary Range Smallest Graduation:
0.1
Connection Size:
1/4 in NPT
Operating Temp. Range:
-40 Degrees to 150 Degrees F
Gauge Accuracy:
+/-0.25%
Basic Gauge Socket Material:
Bronze
Gauge Case Material:
Aluminum
Case Color:
Black
Basic Gauge Lens Material:
Glass
Smallest Graduation:
0.1 psi
Range:
30 in Hg Vac to 0
Basic Gauge Sensor Material:
Bronze
Gauge Panel Mountable:
No
Accuracy Grade:
ASME B40.100 Grade 3A
Panel-Mountable:
No
Pointer Characteristics:
Knife-Edge
Blowout Safety Back:
No
Case Finish:
Epoxy Coated
Scale Type:
Single
Standards:
CRN Registered
Case Depth:
2.875 in
Hazardous Location Rating:
Not Rated
Sensor Type:
Bourdon Tube
Movement Material:
400 Stainless Steel
Dial Face Material:
Aluminum
Primary Scale Units:
in Hg
Sensor Material:
Bronze
Pressure Gauge Type:
Test Pressure Gauge
Lens Material:
Glass
Bezel Material:
Hinged Steel
Ambient Operating Temperature Range:
-20 Degrees to 200 Degrees F, -29 Degrees to 93 Degrees C
Application:
Laboratory, Medical, OEM Applications, Test and Measurement
Removable Bezel:
No
Process Temperature Range:
-20 to 250 Degrees F
Adjustable Pointer:
No
Primary Pressure Range:
30 to 0
Pointer Material:
Aluminum
IP/NEMA Rating:
Not Rated
Process Connection Location:
Bottom
Nominal Dial Size:
4 1/2 in
Cleaned for Oxygen Service:
No
Process Connection Type:
NPT
Pressure Range Type:
Vacuum
Panel Mount Characteristics:
(3) Mounting Studs CC Threaded Equally Spaced on E Dia Bolt Circle
Bolt Circle Diameter:
5.375 in
Case Construction:
Solid Front
Case Diameter:
6.093 in
Accuracy:
+/-0.25%
Primary Scale Minor Graduations:
0.1
Primary Scale Numeric Increments:
2
Process Connection Size:
1/4 in
Movement Type:
Rotary
Dial Color:
White
Accuracy Scale:
Full Scale
Freeze Resistant Movement:
No
Includes Calibration Certificate:
No
For Panel Cut-Out Size:
4.875 in
Process Connection Gender:
Male
Pointer Color:
Black with Red Tip
Primary Pressure Scale Color:
Black
Socket Material:
Brass
Includes Mounting Hardware:
No
Package Quantity:
1
