Vacuum Gauge, 30 Hg to 0, 4-1/2In, 1/2In - 451279SS04LXLLVAC

Vacuum Gauge, 30 Hg to 0, 4-1/2In, 1/2In - 451279SS04LXLLVAC

Ashcroft
SKU:
451279SS04LXLLVAC
|
UPC:
723259699183
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Process Vacuum Gauge, Nominal Dial Size 4 1/2 in, Accuracy +/-0.5 Percent, Gauge Case Material Phenolic, Process Connection Type NPT, Process Connection Gender Male, Lens Material Glass, Process Connection Size 1/2 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 30 to 0, Dry Dampening Feature PLUS! Performance, Vibration Resistance Dry Case Vibration-Dampened, Dial Color White
Additional Information
Country of Origin:
United States
Pressure and Vacuum Gauge Type:
Vacuum Gauge
Gauge Application:
Process
Liquid Filled:
No
Gauge Nominal Dial Size:
4 1/2 in
Basic Gauge Case Material:
Plastic
Basic Gauge Wetted Parts:
Stainless Steel
Gauge Connection Type:
MNPT
Gauge Connection Size:
1/2 in
Gauge Connection Location:
Bottom
Gauge Primary Range Units:
in Hg
Gauge Case Color:
Stainless Steel
Basic Gauge Sensor Material:
Stainless Steel
Gauge Sensor Material:
316 Stainless Steel
Calibration Certificate Included:
No
Gauge Special Options:
PLUS!(TM) Performance
Range:
30 in Hg Vac to 0
Gauge Primary Range Smallest Graduation:
0.2
Gauge Case Material:
Phenolic
Connection Size:
1/2 in NPT
Gauge Primary Range Values:
-30 to 0
Operating Temp. Range:
-40 Degrees to 150 Degrees F
Connection Location:
Lower
Gauge Socket Material:
316 Stainless Steel
Item:
Process Vacuum Gauge
Smallest Graduation:
0.2 in Hg
Basic Gauge Socket Material:
Stainless Steel
Gauge Mounting Method:
Surface
Gauge Accuracy:
+/-0.50%
Basic Gauge Lens Material:
Glass
Series:
1279
Gauge Panel Mountable:
Yes
Gauge Lens Material:
Glass
Case Color:
Black
Field Fillable:
No
Pointer Material:
Aluminum
Bezel Mounting Type:
Threaded
Application:
Chemical Industries, Refrigeration, Mining, Oil and Gas Industry, Power Industries, Turbines and Compressors, Water Purification or Irrigation, Water Pressure Testing
Process Connection Type:
NPT
Case Construction:
Solid Front with Pressure Relief Back
Gauge Case Liquid:
None
Liquid-Filled Case:
No
Includes Vent Plug:
No
Blowout Safety Back:
Yes
Primary Pressure Range:
30 to 0
Accuracy:
+/-0.5%
Panel Mount Characteristics:
3 0.218 Dia Holes on 5 3/8 Dia Bolt Circle
Primary Scale Minor Graduations:
0.2
Dial Color:
White
Pressure Range Type:
Vacuum
Case Diameter:
5.81 in
Bolt Circle Diameter:
5.375 in
Pointer Characteristics:
Micrometer Adjustable
Process Connection Gender:
Male
Includes Mounting Hardware:
No
Bezel Material:
Polycarbonate
Case Depth:
3.36 in
Lens Material:
Glass
Pressure Gauge Type:
Process Pressure Gauge
Removable Bezel:
Yes
Vibration Resistance:
Dry Case Vibration-Dampened
Panel-Mountable:
No
Nominal Dial Size:
4 1/2 in
Hazardous Location Rating:
Not Rated
Movement Type:
Rotary
Standards:
ASME, CRN, UL 94-V-0
Non-Sparking:
No
Sensor Material:
316L Stainless Steel
Primary Pressure Scale Color:
Black
Scale Type:
Single
Process Connection Location:
Bottom
Sensor Type:
Bourdon Tube
IP/NEMA Rating:
Not Rated
Primary Scale Units:
in Hg
Includes Calibration Certificate:
No
Process Temperature Range:
-20 Degrees to 250 Degrees F
Socket Material:
316L Stainless Steel
Dial Face Material:
Aluminum
Cleaned for Oxygen Service:
No
Accuracy Grade:
ASME B40.100 Grade 2A
Ambient Operating Temperature Range:
-20 Degrees to 200 Degrees F (-29 Degrees to 93 Degrees C)
Process Connection Size:
1/2 in
Manufacturer Warranty Length:
10 yr
Compatible Process Media:
Chemical and Petrochemical, Metals, Natural Gas and LNG, Oil and Gas, Water and Wastewater
Freeze Resistant Movement:
No
Movement Material:
400 Stainless Steel
Case Finish:
Teflon(R) Coated
Dry Dampening Feature:
PLUS! Performance
Accuracy Scale:
Full Scale
Package Quantity:
1
