Universal AC/DC Mtr, 1/2hp, 10,000rpm, 115V - 2M145

Universal AC/DC Mtr, 1/2hp, 10,000rpm, 115V - 2M145

Dayton
SKU:
2M145
|
UPC:
190735223000
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Universal AC/DC Motor, Single Phase, Motor Design Universal AC/DC, 1/2 HP, Nameplate RPM 10,000, No. of Speeds 1, 115V AC Voltage, Full Load Amps 6.3, Non-Standard Frame, Usable @ 208V No, Usable @ 200V No, 60 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CCWSE, Motor Enclosure Design Open, Motor Mounting Type Hole, Motor Mounting Position All Angle, Finish Unfinished, Shaft Dia. 3/8 in, Shaft Length 1 1/4 in
Additional Information
Country of Origin:
United States
HP:
1/2
Nameplate RPM:
10,000
Shaft Dia.:
3/8 in
O.C. Mounting:
2 x 2 13/16 in
Mounting Holes:
(4) #10-32
Item:
Universal AC/DC Motor
Voltage:
115V AC
Frame:
Non-Standard
Motor Design:
Universal AC/DC
Motor Enclosure Design:
Open
Max. Ambient Temp.:
40 Degrees C
Length Less Shaft:
6 3/16 in
Motor Bearings:
Ball
RPM Range:
Over 3,600
Standards:
UL Recognized
Shaft Length:
1 1/4 in
Voltage Compatibility:
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Hz:
60
Motor Service Factor:
1
Motor Thermal Protection:
None
Motor Application:
Universal AC/DC Motor
Ins. Class:
A
Motor Mounting Position:
All Angle
Phase:
Single
Overall Length:
7 7/16 in
Motor Shaft Rotation:
CCWSE
Body Dia.:
3 3/4 in
Application:
Used in Appliances, Power Tools, Outdoor Equipment, Food Processing Equipment, Gearmotors, Blowers, Pumps and Other Applications Where High Horsepower Output and Small Size are Required
Average Brush Life:
300 hr
Full Load Amps:
6.3
Motor Mounting Type:
Hole
Usable @ 200V:
No
Usable @ 208V:
No
Motor Shaft Design:
Flat
Replacement Brushes:
1R393
Motor Sub Application:
Belt Drive Fan/Blower
No. of Speeds:
1
Finish:
Unfinished
Weight:
7.45 lb
Package Quantity:
1
