Time Delay Rlay, 12VDC, 10A, DPDT, 0.05 sec. - 5DPZ7

Time Delay Rlay, 12VDC, 10A, DPDT, 0.05 sec. - 5DPZ7

Dayton
SKU:
5DPZ7
|
UPC:
190735342732
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Single Function Time Delay Relay, Adjustment Method Push Button, Rotary Knob, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function On Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 0.05 sec, Maximum Time Setting 999 hr, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
Additional Information
Country of Origin:
United States
Item - Relay:
Single Function Timing Relay
Function - Timing Relay:
On Delay
Coil Volts:
12V DC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
8
Adjustment Method - Timer:
Push Button, Rotary Knob
Min. Time Setting - Timer:
0.05 sec
Max. Time Setting - Timer:
41 day 15 hr
Socket Code:
A
Mounting - Relay:
Plug In
Contact Form - Relay:
DPDT
Hz:
50/60
Mounting:
plug In
Electrical Connection:
Socket
Min. Time Setting:
0.05 sec.
Socket:
1EGP3, 1EGP5, 5X852
Max. Time Setting:
999 hr.
Function:
On Delay
Body Height - Relay:
2.9 in
Item:
Single Function Time Delay Relay
Base Type:
Octal
Adjustment Method:
Push Button, Rotary Knob
Body Width - Relay:
2.4 in
Hz - Electrical:
50 Hz, 60 Hz
Contact Form:
DPDT
Operating Functions:
1
Body Depth - Relay:
1.7 in
Overall Height - Relay:
3 in
Power Consumption - Relay:
3 W
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Status Indicator:
LED
Coil Rating:
3W
Pins:
8
Contact Amp Rating (Resistive):
10A
Contact Material:
Silver Nickel
Input Voltage:
12V DC
Electrical Operating Durability:
100,000
Maximum Time Setting:
999 hr
Delay Function:
On Delay
Minimum Time Setting:
0.05 sec
Reset Method:
Time-Limit Reset
IP Rating:
IP20
Number of Delay Functions:
1
Body Width:
2.4 in
Minimum Operating Temperature:
-18 Degrees F
Base Shape:
Octal
Current Rating:
10 A
Overall Depth:
3 in
Maximum Operating Temperature:
149 Degrees F
Operating Time Accuracy:
+1% +50ms
Mechanical Operating Durability:
10,000,000
Frequency:
50/60 Hz
Flat Pin Width:
Not Applicable
Body Depth:
1.7 in
Contact Rating (AC):
10 A @ 240V
Body Height:
2.9 in
Number of Pins:
8
Mounting Style:
Plug-In
Contact Rating (DC):
10 A @ 30V
Sealing:
Enclosed
Coil Voltage:
12V DC
Power Consumption:
3 VA
Package Quantity:
1
