Time Delay Rlay, 12VDC, 10A, DPDT, 0.05 sec. - 24EN99

Time Delay Rlay, 12VDC, 10A, DPDT, 0.05 sec. - 24EN99

Dayton
SKU:
24EN99
|
UPC:
190735191255
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function On Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 0.05 sec, Maximum Time Setting 5 sec, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In, Body Depth 1.7 in
Additional Information
Country of Origin:
United States
Item - Relay:
Single Function Timing Relay
Function - Timing Relay:
On Delay
Coil Volts:
12V DC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
8
Adjustment Method - Timer:
Potentiometer
Min. Time Setting - Timer:
0.05 sec
Max. Time Setting - Timer:
5 sec
Max. Time Setting:
5 sec.
Status Indicator:
None
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Body Depth - Relay:
1.7 in
Operating Functions:
1
Contact Amp Rating (Resistive):
10A
Body Height - Relay:
2.9 in
Coil Rating:
2W
Power Consumption - Relay:
2 W
Electrical Connection:
Socket
Item:
Single Function Time Delay Relay
Mounting:
plug In
Mounting - Relay:
Plug In
Min. Time Setting:
0.05 sec.
Contact Form - Relay:
DPDT
Contact Material:
Silver Nickel
Hz - Electrical:
50 Hz, 60 Hz
Overall Height - Relay:
3.1 in
Pins:
8
Function:
On Delay
Contact Form:
DPDT
Hz:
50/60
Socket Code:
A
Body Width - Relay:
2.4 in
Adjustment Method:
Potentiometer
Base Type:
Octal
Socket:
1EGP3, 1EGP5, 5X852
Input Voltage:
12V DC
Contact Rating (AC):
10 A @ 240V
IP Rating:
IP20
Number of Pins:
8
Operating Time Accuracy:
+0% -50% (Minimum Setting (Adjustable)), +2% 50ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
Electrical Operating Durability:
100,000
Number of Delay Functions:
1
Frequency:
50/60 Hz
Flat Pin Width:
Not Applicable
Delay Function:
On Delay
Coil Voltage:
12V DC
Reset Method:
Time-Limit Reset
Power Consumption:
2 VA
Sealing:
Enclosed
Overall Depth:
3.1 in
Mechanical Operating Durability:
10,000,000
Mounting Style:
Plug-In
Minimum Time Setting:
0.05 sec
Body Depth:
1.7 in
Maximum Operating Temperature:
122 Degrees F
Base Shape:
Octal
Body Width:
2.4 in
Body Height:
2.9 in
Minimum Operating Temperature:
-18 Degrees F
Maximum Time Setting:
5 sec
Current Rating:
10 A
Contact Rating (DC):
10 A @ 30V
Compatible Grainger Part Number:
1EGP3, 1EGP5, 5X852
Package Quantity:
1
