Time Delay Relay, 240VAC, 10A, DPDT - 5DRA1

Time Delay Relay, 240VAC, 10A, DPDT - 5DRA1

Dayton
SKU:
5DRA1
|
UPC:
190735342756
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Multi-Function Time Delay Relay, Adjustment Method Push Button, Rotary Knob, Base Shape Octal, Coil Voltage 240V AC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 10, Delay Function Multi Function, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 240V AC, Minimum Time Setting 0.05 sec, Maximum Time Setting 999 hr, Number of Pins 11, Sealing Enclosed
Additional Information
Country of Origin:
United States
Item - Relay:
Multi-Function Timing Relay
Function - Timing Relay:
Flasher (Off First), Flasher (On First), Interval On, Off Delay, Off/On Delay, On Delay, One Shot, Single Shot Falling Edge, Triggered On Delay, Watchdog
Coil Volts:
240V AC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
11
Adjustment Method - Timer:
Push Button, Rotary Knob
Min. Time Setting - Timer:
0.05 sec
Max. Time Setting - Timer:
41 day 15 hr
Socket:
1EGP2, 1EGP4, 6X156
Body Height - Relay:
2.9 in
Adjustment Method:
Push Button, Rotary Knob
Coil Rating:
3VA
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Hz - Electrical:
50 Hz, 60 Hz
Operating Functions:
1, 2, 3, 4, 6, 7, 9, 11
Base Type:
Octal
Function:
On Delay, Interval On, Off Delay, Single Shot, Flasher (Off First), Flasher (On First), On/Off Delay, Single Shot Falling Edge, Watchdog, Triggered On Delay
Number of Functions:
10
Body Width - Relay:
2.4 in
Power Consumption - Relay:
3 VA
Contact Form:
DPDT
Contact Material:
Silver Nickel
Electrical Connection:
Socket
Min. Time Setting:
0.05 sec.
Body Depth - Relay:
1.7 in
Max. Time Setting:
999 hr.
Contact Form - Relay:
DPDT
Mounting:
plug In
Pins:
11
Status Indicator:
LED
Overall Height - Relay:
3 in
Item:
Multi-Function Time Delay Relay
Hz:
50/60
Mounting - Relay:
Plug In
Contact Amp Rating (Resistive):
10A
Socket Code:
B
Input Voltage:
240V AC
Body Width:
2.4 in
Body Height:
2.9 in
IP Rating:
IP20
Electrical Operating Durability:
100,000
Overall Depth:
3 in
Delay Function:
Multi Function
Contact Rating (AC):
10 A @ 240V
Minimum Operating Temperature:
-18 Degrees F
Base Shape:
Octal
Sealing:
Enclosed
Maximum Time Setting:
999 hr
Number of Pins:
11
Reset Method:
Time-Limit Reset
Body Depth:
1.7 in
Current Rating:
10 A
Maximum Operating Temperature:
122 Degrees F
Frequency:
50/60 Hz
Number of Delay Functions:
10
Mechanical Operating Durability:
10,000,000
Mounting Style:
Plug-In
Contact Rating (DC):
10 A @ 30V
Minimum Time Setting:
0.05 sec
Operating Time Accuracy:
+1% +50ms
Flat Pin Width:
Not Applicable
Coil Voltage:
240V AC
Power Consumption:
3 VA
Package Quantity:
1
