Time Delay Relay, 12VDC, 10A, DPDT, 3 sec. - 24EP29

Time Delay Relay, 12VDC, 10A, DPDT, 3 sec. - 24EP29

Dayton
SKU:
24EP29
|
UPC:
190735191484
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Cycle On, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 3 sec, Maximum Time Setting 5 min, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In, Body Depth 1.7 in
Additional Information
Country of Origin:
United States
Item - Relay:
Single Function Timing Relay
Function - Timing Relay:
Repeat Cycle (On First)
Coil Volts:
12V DC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
8
Adjustment Method - Timer:
Potentiometer
Min. Time Setting - Timer:
3 sec
Max. Time Setting - Timer:
5 min
Max. Time Setting:
5 Min.
Contact Material:
Silver Nickel
Item:
Single Function Time Delay Relay
Body Width - Relay:
2.4 in
Contact Form - Relay:
DPDT
Min. Time Setting:
3.00 sec.
Function:
Repeat Cycle (On First)
Status Indicator:
None
Hz:
50/60
Operating Functions:
7
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Pins:
8
Socket:
1EGP3, 1EGP5, 5X852
Base Type:
Octal
Adjustment Method:
Potentiometer
Electrical Connection:
Socket
Coil Rating:
2W
Power Consumption - Relay:
2 W
Body Depth - Relay:
1.7 in
Socket Code:
A
Body Height - Relay:
2.9 in
Mounting:
plug In
Contact Amp Rating (Resistive):
10A
Contact Form:
DPDT
Hz - Electrical:
50 Hz, 60 Hz
Overall Height - Relay:
3.1 in
Mounting - Relay:
Plug In
Input Voltage:
12V DC
IP Rating:
IP20
Body Depth:
1.7 in
Minimum Time Setting:
3 sec
Coil Voltage:
12V DC
Mechanical Operating Durability:
10,000,000
Operating Time Accuracy:
+0% -50% (Minimum Setting (Adjustable)), +2% 50ms (Fixed), +5% -0% (Maximum Setting (Adjustable))
Reset Method:
Time-Limit Reset
Sealing:
Enclosed
Electrical Operating Durability:
100,000
Number of Pins:
8
Delay Function:
Cycle On
Maximum Time Setting:
5 min
Base Shape:
Octal
Body Width:
2.4 in
Maximum Operating Temperature:
122 Degrees F
Number of Delay Functions:
1
Flat Pin Width:
Not Applicable
Mounting Style:
Plug-In
Contact Rating (AC):
10 A @ 240V
Frequency:
50/60 Hz
Minimum Operating Temperature:
-18 Degrees F
Current Rating:
10 A
Contact Rating (DC):
10 A @ 30V
Power Consumption:
2 VA
Body Height:
2.9 in
Overall Depth:
3.1 in
Package Quantity:
1
