Time Delay Relay, 12VDC, 10A, DPDT, 0.6 sec. - 24EN66

Time Delay Relay, 12VDC, 10A, DPDT, 0.6 sec. - 24EN66

Dayton
SKU:
24EN66
|
UPC:
190735190975
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Interval On, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 0.6 sec, Maximum Time Setting 60 sec, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
Additional Information
Country of Origin:
United States
Item - Relay:
Single Function Timing Relay
Function - Timing Relay:
Interval On
Coil Volts:
12V DC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
8
Adjustment Method - Timer:
Potentiometer
Min. Time Setting - Timer:
0.6 sec
Max. Time Setting - Timer:
1 min
Contact Form:
DPDT
Min. Time Setting:
0.60 sec.
Hz:
50/60
Operating Functions:
4
Mounting - Relay:
Plug In
Contact Form - Relay:
DPDT
Mounting:
plug In
Body Height - Relay:
2.9 in
Socket Code:
A
Electrical Connection:
Socket
Function:
Interval On
Body Depth - Relay:
1.7 in
Contact Material:
Silver Nickel
Base Type:
Octal
Body Width - Relay:
2.4 in
Overall Height - Relay:
3.1 in
Adjustment Method:
Potentiometer
Item:
Single Function Time Delay Relay
Contact Amp Rating (Resistive):
10A
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Socket:
1EGP3, 1EGP5, 5X852
Max. Time Setting:
60 sec.
Hz - Electrical:
50 Hz, 60 Hz
Pins:
8
Status Indicator:
None
Power Consumption - Relay:
2 W
Coil Rating:
2W
Input Voltage:
12V DC
Base Shape:
Octal
Body Height:
2.9 in
Minimum Time Setting:
0.6 sec
Contact Rating (DC):
10 A @ 30V
Reset Method:
Time-Limit Reset
Contact Rating (AC):
10 A @ 240V
Coil Voltage:
12V DC
Mounting Style:
Plug-In
Body Width:
2.4 in
Body Depth:
1.7 in
Frequency:
50/60 Hz
Number of Delay Functions:
1
Power Consumption:
2 W
Flat Pin Width:
Not Applicable
Sealing:
Enclosed
Overall Depth:
3.1 in
Delay Function:
Interval On
Maximum Time Setting:
60 sec
Number of Pins:
8
Current Rating:
10 A
IP Rating:
IP20
Package Quantity:
1
