Time Delay Relay, 12VDC, 10A, DPDT, 0.1 sec. - 24EN65

Time Delay Relay, 12VDC, 10A, DPDT, 0.1 sec. - 24EN65

Dayton
SKU:
24EN65
|
UPC:
190735190968
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 12V DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function Interval On, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 12V DC, Minimum Time Setting 0.1 sec, Maximum Time Setting 10 sec, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
Additional Information
Country of Origin:
United States
Item - Relay:
Single Function Timing Relay
Function - Timing Relay:
Interval On
Coil Volts:
12V DC
AC Contact Rating - Relay:
10A @ 240V
DC Contact Rating - Relay:
10A @ 30V
Base Type - Plug In Relay:
Octal
Number of Pins - Relay:
8
Adjustment Method - Timer:
Potentiometer
Min. Time Setting - Timer:
0.1 sec
Max. Time Setting - Timer:
10 sec
Body Width - Relay:
2.4 in
Max. Time Setting:
10 sec.
Contact Form - Relay:
DPDT
Function:
Interval On
Overall Height - Relay:
3.1 in
Electrical Connection:
Socket
Base Type:
Octal
Adjustment Method:
Potentiometer
Body Depth - Relay:
1.7 in
Socket Code:
A
Contact Amp Rating (Resistive):
10A
Coil Rating:
2W
Power Consumption - Relay:
2 W
Body Height - Relay:
2.9 in
Min. Time Setting:
0.10 sec.
Standards:
CE Certified, CSA Certified, UL Listed, UL Socket
Mounting:
plug In
Hz - Electrical:
50 Hz, 60 Hz
Pins:
8
Contact Form:
DPDT
Operating Functions:
4
Socket:
1EGP3, 1EGP5, 5X852
Status Indicator:
None
Contact Material:
Silver Nickel
Item:
Single Function Time Delay Relay
Hz:
50/60
Mounting - Relay:
Plug In
Input Voltage:
12V DC
Flat Pin Width:
Not Applicable
Current Rating:
10 A
Body Height:
2.9 in
Mounting Style:
Plug-In
Overall Depth:
3.1 in
Contact Rating (AC):
10 A @ 240V
Minimum Time Setting:
0.1 sec
Contact Rating (DC):
10 A @ 30V
Body Depth:
1.7 in
Coil Voltage:
12V DC
Sealing:
Enclosed
Number of Pins:
8
Maximum Time Setting:
10 sec
Body Width:
2.4 in
Delay Function:
Interval On
Frequency:
50/60 Hz
IP Rating:
IP20
Number of Delay Functions:
1
Base Shape:
Octal
Power Consumption:
2 W
Reset Method:
Time-Limit Reset
Compatible Grainger Part Number:
1EGP3, 1EGP5, 5X852
Package Quantity:
1
