Threading Tool, 2-1/2 in L, Carbide - IT-360750

Threading Tool, 2-1/2 in L, Carbide - IT-360750

Micro 100
SKU:
IT-360750
|
UPC:
728709138274
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Threading Tool, Included Angle 60 Degrees , Carbide, Bright (Uncoated), 0.1725 in, Threading
Additional Information
Country of Origin:
United States
Item:
Threading Tool
Overall Length:
2-1/2 in
Shank Dia.:
3/8 in
Max. Depth:
0.750";Cutting Direction=Right Hand"
Material:
C2 Micrograin Carbide
Shank Material:
Carbide
Style:
Internal Threading Tool
Projection:
0.0490 in
Finish:
Uncoated
Hole Dia.:
.360";Radius=0.0020""
Thread Direction:
Right Hand
Measurement System:
Fractional Inch
Min. Hole Dia.:
0.3600 in
Shank Type - Machining:
Straight with Three Flats
Center to Cutting Tip:
0.1725 in
Min. Teeth per Inch:
10
Finish - Machining:
Bright (Uncoated)
Offset Point:
0.0490 in
Included Angle:
60 Degrees
Cutter Material:
Carbide
Features:
Polished Split Face for Improved Edge Retention and Chip Evacuation While Reducing Galling, Split Geometry Makes the Tool as Rigid as Possible
Max. Threads per Inch:
32
Series:
IT
Max. Hole Depth:
3/4 in
Thread Standard:
ANSI, Metric 60 Degrees , UN
Cutting Application:
Threading
Offset:
0.049";Max. Bore Depth=3/4""
Neck Dia.:
0.2700";Min. Bore Dia.=0.3600""
Thread Size:
11-28
Split Length:
0.210";Groove Width=0.0980""
Package Quantity:
1
