Surge Protection Device, 1 Phase, 120V AC, 1 Poles, 2 Wires - STP120P07

Surge Protection Device, 1 Phase, 120V AC, 1 Poles, 2 Wires - STP120P07

Mersen
SKU:
STP120P07
|
UPC:
782001477882
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Surge Protection Device, Nonmetallic, Gray, Amps 75 kA, Depth 2.81 in, Enclosure Material Polyethylene Terephthalate, Enclosure NEMA Rating 1
Additional Information
Country of Origin:
Mexico
CAD Available:
Yes
Item:
Surge Protection Device
Mounting Style:
DIN Rail
Phase:
1
Voltage:
120V AC
Number of Poles:
1
Voltage Protection Rating:
600V (L-N)
Number of Wires:
2 Wires
Modes of Protection:
L-N
Max. Surge Current Per Mode:
75kA
Max. Surge Current per Mode:
75 kA
Max. Surge Current per Phase:
75 kA
Nominal Discharge Current:
20 kA
Short Circuit Current Rating:
200kA
Modular:
Yes
Filtering:
No
Max. Continuing Operating Voltage:
175V AC
Enclosure NEMA Rating:
NEMA 1
IP Rating:
IP20
Enclosure Material:
Thermoplastic
Length:
4.19 in
Depth:
2.81 in
Width:
0.69 in
Wire Gauge:
14 to 4 AWG
Includes:
Mechanical Indication
Modular / Nonmodular:
Modular
Lightning Impulse Current:
75 kA
Standards:
ANSI/UL 1449 4th Edition, ANSI/IEEE C62.41.1, C62.41.2, C62.45, RoHS Compliant, Type 1
Color:
Gray
Min. Operating Temp.:
-40 Degrees F
System Connection:
Parallel
Max. Operating Temp.:
185 Degrees F
Amps:
75 kA
UL SPD Type:
Type 1
Includes Surge Counter:
No
Status Indicator:
Mechanical Flag
Short Description:
SPD - Plugable STP 75 Series 120V L-N VPR 600V L-N MCOV 175V 75 kA 1-pole
Wire Connections:
Box
Item Description (ERP):
STP T1 75kA 120V 1P
System Configuration:
Single Phase
Flammability Rating:
UL94 V0
Max Discharge Current:
Imax (8/20)
Wire Type:
Solid / Stranded CU
MOV Response Time:
<25 ns
Replacement Plug L1:
SP07U175
Connection Terminal Type:
Box
Ac Or Dc:
AC
Max Storage Temp:
85 °C
Max Discharge Current Imax 8 20:
75kA
APPROVALS & STANDARDS:
ANSI/UL 1449 4th Edition,; ANSI/IEEE C62.41.1, C62.41.2,
Max Operating Temp:
85 °C
Wiring Range:
#4 to #14 AWG
Frequency:
50/60 Hz
Connection/Terminal Type:
Box
Mcov L-N:
175 V
Min Storage Temp:
-40 °C
Min Operating Temp:
-40 °C
Response Time:
<25 ns
Housing Material:
PET (Polyethelene Terphthalate)
Torque Rating:
35.4 lb-in
Protection Modes:
L-N
Installation Mounting:
DIN Rail
Package Quantity:
1
