Standard-Duty Quiet-Design Industrial Fan 20" Non-Oscillating, 115VAC, 1657/2060/3100 CFM - 20933

Standard-Duty Quiet-Design Industrial Fan 20" Non-Oscillating, 115VAC, 1657/2060/3100 CFM - 20933

Dayton
SKU:
20933
|
UPC:
190735331897
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Standard-Duty Quiet-Design Industrial Fan, Blade Dia. 20 in, Stationary, Non-Oscillating, 3 Speeds, Voltage 115V AC, 1 Phase, CFM High 3100, CFM Low 1657, Air Velocity @ 20 Ft. 275 fpm, Motor HP 1/5 hp, Motor RPM 1120/745/600, Operating Amps 1.65, Fan Mounting Location Wall, Fan Accessory Style Quiet Design, Fan RPM 1120, Sound Level 69/60/57 dBA, Max. Ambient Temp. 105 Degrees F, Hz 60 Hz, Watts 193, Motor Type Permanent Split Capacitor, Drive Type Direct Drive, Outside Dia. 23 In.
Additional Information
Country of Origin:
United States
Item:
Standard-Duty Quiet-Design Industrial Fan
Blade Diameter:
20";Oscillation=Non-Oscillating"
Air Flow:
1657/2060/3100 CFM
Voltage:
115VAC
Number of Speeds:
3
Motor HP:
1/5
Material:
Steel
Number of Blades:
3
Includes:
Mounting Device and Mounting Bolts
Phase:
1
Height:
23-7/16";Bearing Type=Ball"
Width:
23-7/16";Motor Insulation=Class B"
Motor RPM:
1120/745/600
Speeds:
3
Max. Ambient Temp.:
105 Degrees F
Fan Style:
Quiet Design
Assembled:
No
Max. Depth:
21-3/4";Guard Material=Steel"
CFM High:
3100
CFM Medium:
2060
Fan RPM:
1120
Number of Conductors:
3
Housing Material:
Steel
Motor Type:
Permanent Split Capacitor
Environmental Applications:
Industrial
NEMA Plug Configuration:
5-15P
Thermal Protection:
Auto
Drive Type:
Direct
CFM/Watt:
16
Oscillating / Non-Oscillating:
Non-Oscillating
Outside Dia.:
23";Shaft Dia.=5/8""
Fan Accessory Style:
Quiet Design
Full Load Amps:
1.65
Air Velocity (FPM) @ 10 Ft.:
586
CFM Low:
1657
Application:
Spot Cooling and People Cooling
Requires:
Requires Assembly
Operating Amps:
1.65
Air Velocity (FPM) @ 20 Ft.:
275
Hz:
60
Air Velocity @ 40 Ft.:
145
Wire Guard Finish:
Nickel Chrome
Air Velocity @ 10 Ft.:
586
Motor Enclosure:
Totally Enclosed Air-Over
Oscillating:
No
Air Velocity @ 20 Ft.:
275
Fan Mounting Location:
Wall
Mobile/Stationary:
Stationary
Air Velocity (FPM) @ 40 Ft:
145
Standards:
UL, cUL, OSHA
Watts:
193
Blade Material:
Cast Aluminum
Sound Level:
69/60/57dBA
Blade Dia.:
20";Cord Length=15 ft."
Frame Material:
Steel
Fan Housing Material:
Steel
Depth:
21 3/4 in
Assembly Required:
Yes
Wheeled Base:
Stationary
RPM:
1120
Amps:
1.65
Fan Cord Length:
15 ft
Package Quantity:
1
