Spring Return Hose Reel, 1 in Hose Dia., 35 ft Length, 300 psi - TSHF-N-635

Spring Return Hose Reel, 1 in Hose Dia., 35 ft Length, 300 psi - TSHF-N-635

Coxreels
SKU:
TSHF-N-635
|
UPC:
674255721968
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Spring Return Hose Reel, Fuel, 300 psi, Hose Capacity 35 ft (1 in I.D.), Drive Type Spring Return, Enclosed No, Includes Hose Yes, Hose Inside Dia. 1 in, Hose Length 35 ft, Reel Material Steel, Mounting Location Ceiling, Floor, Truck, Wall, Speed Limited Retraction No, Overall Height 25 1/2 in, Overall Length 24 in, Overall Width 10 in, Corrosion-Resistant Yes, For Dual Hose No, Hose Color Red, Hose Cover Material Synthetic Rubber, Hose Fitting A Gender Male
Additional Information
Country of Origin:
United States
Duty Rating:
Heavy Duty
Finish - Hose Reels:
Powder Coated
Hose Included:
Yes
Hose Inside Dia.:
1 in
Hose Length:
35 ft
Housing Material:
Steel
Max. Pressure:
300 psi
Media - Hose Reels:
Diesel, Kerosene, Fuel Oil and Heating Oil
Mounting:
Bench and Vehicles, Ceiling, Floor, Wall
Overall Length:
24 in
Overall Width:
10 in
Application:
Fuel
Hose Outlet:
1 in (M)NPT
Includes:
Hose, Hose Stop
Max. Temp.:
150 Degrees F
Overall Height:
25 1/2 in
Reel Inlet:
1 in (F)NPT
Enclosed Reel:
No
Item:
Spring Return Hose Reel
Swivel Material:
Nickel Plated Steel
Drive Type - Hose Reels:
Spring Return
Hose Ends:
1 in (M)NPT
Bearings:
Permanently Lubricated
Seal Type:
Nitrile
Latch:
Locking
Hose Material:
Nitrile Synthetic Rubber
Drive Type:
Spring Return
Width:
10 in
Height:
25 1/2 in
Features:
1 Solid Steel Axle, External Fluid Path, Heavy Gauge 1/4" Steel Base & Support Post For Maximum Stability, Long Lasting & Chip Resistant Rust Inhibiting CPC Powder Coat Finish, Multi-Position Lock Ratchet Mechanism Secures Hose At Desired Length, Non
Length:
23 in
Hose Outside Dia.:
1 1/2 in
Reel Width:
10 in
Hose End Configuration:
1 in MNPT
Twin Hose Compatible:
No
Swivel Inlet Type:
NPT
Overall Dimensions:
24 in L x 10 in W x 25 1/2 in H
Fitting Size:
1 in x 1 in
Swivel Outlet Thread Size:
1 in - 11 1/2
Corrosion-Resistant:
Yes
Reel Material:
Steel
Includes Leader Hose:
No
Bearing Construction:
Permanently Lubricated
Minimum Operating Temperature:
-20 Degrees F
Hose Reel Primary Application:
Fuel
For Dual Hose:
No
Fasteners Included:
No
Hose Fitting A Material:
Brass
Base Motion Type:
Stationary
Fitting Type:
NPT x NPT
Mount Hole Diameter:
1/2 in
Reel Diameter:
24 in
Pedestal Type:
Dual Pedestal
Hose Fitting B Gender:
Male
Swivel Outlet Gender:
Male
Weight:
95 lb
Latch Type:
Locking
Reel Color:
Blue
Hose Reel Type:
Wall Mount Hose Reel
Number of Mount Holes:
4
Maximum Operating Temperature:
190 Degrees F
Hose Fitting B Type:
NPT
Reel Finish:
Powder Coated
Swivel Outlet Type:
NPT
Hose Cover Material:
Synthetic Rubber
Number of Guide Arms:
Double Arm
Swivel Inlet Thread Size:
1 in - 11 1/2
Includes Hose Stop:
Yes
Hose Fitting B Material:
Brass
Speed Limited Retraction:
No
Mounting Hole Center to Center Width:
7 in
Mount Base Width:
8 in
Hose Fitting B Size:
1 in
Swivel Inlet Gender:
Female
Swivel Inlet Size:
1 in
Swivel Outlet Size:
1 in
Hose Fitting A Type:
NPT
Includes Hose:
Yes
Hose Fitting A Gender:
Male
Spiral Hose Guard:
No
Maximum Operating Pressure:
300 psi
Mount Base Height:
9 in
Enclosed:
No
Hose Tube Material:
Synthetic Rubber
Hose Capacity:
35 ft (1 in I.D.)
Hose Color:
Red
Mounting Hole Center to Center Height:
8 in
Hose Fitting A Size:
1 in
Standards:
CE
Type:
Dual Pedestal
Package Quantity:
1
