Spring Return Hose Reel, 1/2 in Hose Dia., 35 ft Length, 300 psi - RT835-OLP

Spring Return Hose Reel, 1/2 in Hose Dia., 35 ft Length, 300 psi - RT835-OLP

Reelcraft
SKU:
RT835-OLP
|
UPC:
699567009504
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Spring Return Hose Reel, Air, Water, 300 psi, Hose Capacity 35 ft (1/2 in I.D.), Drive Type Spring Return, Enclosed No, Includes Hose Yes, Hose Inside Dia. 1/2 in, Hose Length 35 ft, Reel Material Carbon Steel, Mounting Location Ceiling, Floor, Wall, Speed Limited Retraction No, Overall Height 17 7/8 in, Overall Length 16 1/2 in, Overall Width 6 1/4 in, Corrosion-Resistant Yes, For Dual Hose No, Hose Color Red, Hose Cover Material PVC, Hose Fitting A Gender Male
Additional Information
Country of Origin:
United States
Duty Rating:
Light Duty
Finish - Hose Reels:
Powder Coated
Hose Included:
Yes
Hose Inside Dia.:
1/2 in
Hose Length:
35 ft
Housing Material:
Steel
Max. Pressure:
300 psi
Media - Hose Reels:
Air, Water
Overall Length:
16 1/2 in
Overall Width:
6 1/4 in
Application:
Industrial and Commercial
Item:
Spring Return Hose Reel
Hose Outlet:
1/2 in (M)NPT
Hose Material:
PVC
Bearings:
Permanently Lubricated
Latch:
Locking
Max. Temp.:
150 Degrees F
Reel Inlet:
1/2 in (F)NPT
Enclosed Reel:
No
Swivel Material:
Nickel Plated Steel
Overall Height:
17 7/8 in
Drive Type - Hose Reels:
Spring Return
Hose Ends:
1/2 in (M)NPT
Includes:
Hose; Bumper
Drive Type:
Spring Return
Hose Outside Dia.:
3/4 in
Reel Width:
6 1/4 in
Features:
Guide Arm Adjusts To Seven Positions, Industrial and Commercial Use
Bearing Construction:
Permanently Lubricated
Hose Reel Type:
Ceiling, Floor, Wall Mount Hose Reel
Swivel Inlet Gender:
Female
Base Motion Type:
Stationary
Speed Limited Retraction:
No
Hose End Configuration:
1/2 in MNPT
Includes Leader Hose:
No
Hose Fitting A Type:
NPT
Reel Color:
Black, Red
Reel Diameter:
7 11/16 in
Number of Mount Holes:
4
Maximum Operating Pressure:
300 psi
Mount Hole Diameter:
5/16 in
Minimum Operating Temperature:
32 Degrees F
Includes Hose:
Yes
Hose Fitting B Gender:
Male
Number of Guide Arms:
Single Arm
Swivel Inlet Size:
1/2 in
For Dual Hose:
No
Hose Fitting A Gender:
Male
Overall Dimensions:
16 1/2 in L x 6 1/4 in W x 17 7/8 in H
Hose Tube Material:
PVC
Pedestal Type:
Single Pedestal
Swivel Inlet Thread Size:
1/2 in - 14
Swivel Inlet Type:
NPT
Swivel Outlet Size:
1/2 in
Swivel Outlet Thread Size:
1/2 in - 14
Weight:
21 lb
Twin Hose Compatible:
No
Hose Color:
Red
Mount Base Height:
8 in
Hose Cover Material:
PVC
Hose Fitting A Material:
Brass
Maximum Operating Temperature:
150 Degrees F
Hose Fitting B Material:
Brass
Fitting Type:
NPT x NPT
Mounting Hole Center to Center Width:
2 1/4 in
Mount Base Width:
4 19/32 in
Hose Capacity:
35 ft (1/2 in I.D.)
Latch Type:
Spring Loaded
Hose Fitting B Type:
NPT
Hose Fitting B Size:
1/2 in
Fasteners Included:
No
Reel Material:
Carbon Steel
Hose Fitting A Size:
1/2 in
Hose Reel Primary Application:
Air, Water
Enclosed:
No
Mounting Hole Center to Center Height:
6 in
Swivel Outlet Gender:
Male
Swivel Outlet Type:
NPT
Spiral Hose Guard:
No
Includes Hose Stop:
Yes
Fitting Size:
1/2 in x 1/2 in
Corrosion-Resistant:
Yes
Package Quantity:
1
