Speed Reducer, Indirect Drive, 26:1 - 2Z308
DaytonLog in for pricing
(No reviews yet)
Write a Review
Dayton
Speed Reducer, Indirect Drive, 26:1 - 2Z308
Speed Reducer, Input Connection Type Indirect Drive, Gear Type Worm, Output Shaft Type Round, Maximum Output Speed 67 RPM, Worm Center Distance 2.06 in, Gear Ratio 26:1, Rotation CW/CCW, Maximum Input Horsepower 0.75 hp, Maximum Output Torque 385 in-lb, Overhung Load Capacity 600 ft-lb, Housing Material Cast Aluminum, Application Speed Reducer, Bearing Type Tapered Roller, Gear Material Hardened and Ground Steel, Housing Material Finish Powder Coated Epoxy Paint
- Country of Origin:
- United States
- Item:
- Speed Reducer
- Nominal Ratio:
- 26
- Input RPM:
- 1750 rpm
- Standards:
- AGMA
- Number of Stages:
- 1
- Worm Gear Material:
- Bronze
- Rotation:
- CW/CCW
- Output Torque @ 1/4 HP:
- 115 in-lb
- Overhung Load:
- 600 lb
- Max. Input HP:
- 0.75 hp
- Solid/Hollow Output Shaft:
- Solid
- Finish:
- Powdered Epoxy Paint
- Output Torque @ 1/8 HP:
- 58 in-lb
- Pinion Material:
- Hardened Steel
- Output Torque @ 1/3 HP:
- 154 in-lb
- Reducer Model No.:
- 84258
- Output Shaft Dia.:
- 3/4 in
- Gear Type:
- Worm
- Max. Output Torque:
- 385 in-lb
- Gear Material:
- Hardened and Ground Steel
- Shaft Orientation:
- Right Angle
- Duty:
- Standard
- Worm Center Distance:
- 2.06 in
- Output Torque @ 1/6 HP:
- 77 in-lb
- Seal Type:
- Double Lip
- Output Torque @ 1/2 HP:
- 231 in-lb
- Lubrication:
- Klubersynth UH1 6-460
- Output Torque @ 3/4 HP:
- 385 in-lb
- Bearings:
- Tapered Roller
- Speed Reducer Type:
- Indirect Drive
- Housing Material:
- Cast Aluminum
- Output Torque @ 1/40 HP:
- 3600 in.-lb.
- Single/Double Output/Universal:
- Single Output
- Output Torque @ 1 HP:
- 385 in.-lb.
- Dimension U:
- 3/4 in
- Application:
- Speed Reducer
- Overhung Load Capacity:
- 600 ft-lb
- Input Connection Type:
- Indirect Drive
- Bearing Type:
- Tapered Roller
- Housing Material Finish:
- Powder Coated Epoxy Paint
- Output Shaft Diameter:
- 3/4 in
- Maximum Output Speed:
- 67 RPM
- Maximum Input Horsepower:
- 0.75 hp
- Maximum Input Speed:
- 1,750 RPM
- Gear Ratio:
- 26
- Output Shaft Type:
- Round
- Maximum Output Torque:
- 385 in-lb
- Package Quantity:
- 1
