Speed Reducer, C-Face, 56C, 10:1 - SSF718-10K-B5-GS1
Boston GearLog in for pricing
(No reviews yet)
Write a Review
Boston Gear
Speed Reducer, C-Face, 56C, 10:1 - SSF718-10K-B5-GS1
Speed Reducer, Input Connection Type C-Face, Gear Type Worm, Output Shaft Type Round, Maximum Output Speed 175 RPM, Motor Frame Designation 56C, Worm Center Distance 1.75 in, Base to Center 2.06 in, Gear Ratio 10:1, Rotation CW/CCW, Maximum Input Horsepower 1 hp, Maximum Output Torque 460 in-lb, Overhung Load Capacity 600 ft-lb, Mounting Orientation Any Angle, Housing Material Stainless Steel, Shaft Center-to-Center Height 1.75 in, Bearing Type Tapered Roller
- Country of Origin:
- United States
- Item:
- Speed Reducer
- Nominal Ratio:
- 10
- Input RPM:
- 1750 rpm
- Bore Dia.:
- 5/8";Nominal Output RPM=175 RPM"
- Overall Length:
- 7-1/2";Standards=Nsf"
- Frame:
- 56c
- Max. Output Torque:
- 460 in-lb
- Max. Input HP:
- 1 hp
- Dimension B:
- 7.5 in
- Lubrication:
- Klubersynth UH1 6-460
- Gear Material:
- Hardened and Ground Steel
- Mounting:
- Any Position
- Shaft Orientation:
- Right Angle
- Output Torque @ 1/40 HP:
- 3600 in.-lb.
- Dimension W:
- 1.780 in
- Dimension F:
- 5.63 in
- Rotation:
- CW/CCW
- Speed Reducer Type:
- C-Face
- Dimension H:
- 5.31 in
- Output Shaft Dia.:
- 7/8 in
- Finish:
- 316 Stainless Steel
- Gear Type:
- Worm
- Housing Material:
- Stainless Steel
- Seal Type:
- Double Lip
- Overhung Load:
- 600 lb
- Reducer Model No.:
- SSF718-10-K-B5-GS
- Number of Stages:
- 1
- Duty:
- Washdown
- Pinion Material:
- Hardened Steel
- Worm Gear Material:
- Bronze
- Dimension A:
- 3.69 in
- Base:
- Optional
- Solid/Hollow Output Shaft:
- Solid
- Worm Center Distance:
- 1.75 in
- Output Torque @ 1.5 HP:
- 460 in-lb
- Output Shaft Height:
- 2 1/16 in
- Single/Double Output/Universal:
- Single Output
- Bearings:
- Tapered Roller
- Dimension U:
- 7/8 in
- Output Torque @ 1 HP:
- 320 in-lb
- Nominal Output rpm:
- 175 rpm
- Maximum Output Speed:
- 175 RPM
- Gear Ratio:
- 10
- Input Keyway Depth:
- 1/8 in
- Shaft Material Grade:
- Type 303
- Motor Frame Designation:
- 56C
- Input Keyway Width:
- 3/16 in
- Mount Hole Center-to-Center Width:
- 2.75 in
- Output Shaft Type:
- Round
- Mount Hole Center-to-Center Length:
- 4.19 in
- Maximum Input Horsepower:
- 1 hp
- Shaft Center-to-Center Height:
- 1.75 in
- Number of Housing Mount Holes:
- 4
- Maximum Input Speed:
- 1,750 RPM
- Input Shaft Diameter:
- 5/8 in
- Base to Center:
- 2.06 in
- Overhung Load Capacity:
- 600 ft-lb
- Overall Height:
- 5.31 in
- Mounting Orientation:
- Any Angle
- Bearing Type:
- Tapered Roller
- Overall Width:
- 6.74 in
- Maximum Output Torque:
- 460 in-lb
- Housing Material Grade:
- 316
- Output Shaft Diameter:
- 7/8 in
- Output Keyway Width:
- 3/16 in
- Gear Material Grade:
- Type 316
- Output Keyway Depth:
- 3/16 in
- Input Connection Type:
- C-Face
- Housing Mount Hole Size:
- 5/16-18
- Package Quantity:
- 1
