Speed Reducer, C-Face, 140TC/180C, 60:1 - F732-60E-B7-G

Speed Reducer, C-Face, 140TC/180C, 60:1 - F732-60E-B7-G

Boston Gear
SKU:
F732-60E-B7-G
|
UPC:
781711520833
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Speed Reducer, Input Connection Type C-Face, Gear Type Worm, Output Shaft Type Round, Maximum Output Speed 29 RPM, Motor Frame Designation 140TC/180C, Worm Center Distance 3.25 in, Base to Center 3.5 in, Gear Ratio 60:1, Rotation CW/CCW, Maximum Input Horsepower 1.5 hp, Maximum Output Torque 2009 in-lb, Overhung Load Capacity 1,300 ft-lb, Mounting Orientation Any Angle, Housing Material Cast Iron, Bearing Type Tapered Roller, Gear Material Hardened and Ground Steel
Additional Information
Country of Origin:
United States
Item:
Speed Reducer
Nominal Ratio:
60
Input RPM:
1,750 RPM
Bore Dia.:
7/8 in
Nominal Output RPM:
29 RPM
Standards:
AGMA
Output Torque @ 1.5 HP:
1,340 in-lb
Finish:
Powdered Epoxy Paint
Worm Gear Material:
Bronze
Duty:
Standard
Shaft Orientation:
Right Angle
Overhung Load:
1,300 lb
Mounting:
Any Position
Seal Type:
Double Lip
Max. Output Torque:
2,009 in-lb
Dimension U:
1 3/8 in
Output Torque @ 2 HP:
2,009 in-lb
Rotation:
CW/CCW
Output Shaft Height:
3 1/2 in
Max. Input HP:
1.5 hp
Bearings:
Tapered Roller
Gear Material:
Hardened and Ground Steel
Pinion Material:
Hardened Steel
Worm Center Distance:
3.25 in
Output Torque @ 1/40 HP:
3600 in.-lb.
Base:
Optional
Reducer Model No.:
F732-60-B7-G
Speed Reducer Type:
C-Face
Output Shaft Dia.:
1 3/8 in
Housing Material:
Cast Iron
Number of Stages:
1
Single/Double Output/Universal:
Single Output
Gear Type:
Worm
Lubrication:
Klubersynth UH1 6-460
Solid/Hollow Output Shaft:
Solid
Frame:
140TC/180C
Output Shaft Diameter:
1 3/8 in
Input Shaft Diameter:
7/8 in
Overhung Load Capacity:
1,300 ft-lb
Bearing Type:
Tapered Roller
Maximum Output Speed:
29 RPM
Base to Center:
3.5 in
Maximum Input Speed:
1,750 RPM
Motor Frame Designation:
140TC/180C
Maximum Input Horsepower:
1.5 hp
Maximum Output Torque:
2009 in-lb
Gear Ratio:
60
Housing Material Finish:
Powder Coated Epoxy Paint
Mounting Orientation:
Any Angle
Output Shaft Type:
Round
Input Connection Type:
C-Face
Package Quantity:
1
