Shaft Collar, Clamp, 2Pc, 2-13/16 In, Alum - SP-45-A

Shaft Collar, Clamp, 2Pc, 2-13/16 In, Alum - SP-45-A

Ruland
SKU:
SP-45-A
|
UPC:
634529021521
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Shaft Collar, System of Measurement Inch, Bore Type Round, Bore Diameter 2 13/16 in, Bore Thread Size Not Applicable, Collar Outside Diameter 4 1/4 in, Inside Height to Flat Not Applicable, Clearance Diameter 4.5 in, Collar Width 7/8 in, Collar Material Aluminum, Keyway Width Not Applicable, Collar Material Grade 2024, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 2-Piece, Screw Material Alloy Steel
Additional Information
Country of Origin:
United States
Bore Dia.:
2 13/16 in
Material:
2024 Aluminum
Number of Pieces:
2
Collar Style:
Clamp
Outside Dia.:
4 1/4 in
Dimension Type:
Inch
Width:
7/8 in
Screw Size:
3/8-24"
Operating Temp. Range:
-40 Degrees to 225 Degrees F
Clearance Dia.:
4.499 in
Screw Material:
Alloy Steel
Bore Type - Collars:
Plain Bore
Item:
Shaft Collar
Item - Shaft Collars:
Shaft Collar
Material - Collars:
2024 Aluminum
Shaft Locking Type - Couplings:
2 Piece Clamp
System of Measurement:
Inch
Standards:
ANSI, Conflict Minerals Compliant, ISO 9001
Bore Tolerance:
+0.002/+0.0005 in
Width Tolerance:
+0.003/-0.010 in
Distance Across Flats:
Not Applicable
Screw Seating Torque:
570 lb-in
Collar Width:
7/8 in
Bore Width:
Not Applicable
Inside Height to Flat:
Not Applicable
Collar Outside Diameter:
4 1/4 in
Lever Part Number:
Not Applicable
Shaft Locking Type:
Clamp On
Collar Material Finish:
Bright
Handle Material:
Not Applicable
Handle Color:
Not Applicable
Screw Location from Center:
1.81 in
Component Mount Type:
Not Applicable
Included Screws:
(2) Hex Socket Cap Screw
Flat to Bore:
Not Applicable
Minimum Operating Temperature:
-40 Degrees F
Resistance Properties:
Not Applicable
Lever Length:
Not Applicable
Collar Material Grade:
2024
Shaft Tolerance:
+0.0000/-0.0005 in
Clearance Diameter:
4.5 in
Thread Direction:
Not Applicable
Maximum Operating Temperature:
225 Degrees F
Collar Construction:
2-Piece
Bore Thread Size:
Not Applicable
Mount Hole Thread Size:
Not Applicable
Keyway Width:
Not Applicable
Center to Lever Top:
Not Applicable
Keyway Depth:
Not Applicable
Lever Height:
Not Applicable
Handle Material Finish:
Not Applicable
Screw Thread Size:
3/8-24"
For Shaft Diameter:
2 13/16 in
Bore Diameter:
2 13/16 in
Bore Type:
Round
Collar Material:
Aluminum
Screw Material Finish:
Black Oxide
Package Quantity:
1
