Shaft Collar, Clamp, 1Pc, 48mm, 303 SS - MCL-48-SS

Shaft Collar, Clamp, 1Pc, 48mm, 303 SS - MCL-48-SS

Ruland
SKU:
MCL-48-SS
|
UPC:
634529012611
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Shaft Collar, System of Measurement Metric, Bore Type Round, Bore Diameter 48 mm, Bore Thread Size Not Applicable, Collar Outside Diameter 78 mm, Inside Height to Flat Not Applicable, Clearance Diameter 84.7 mm, Collar Width 19 mm, Collar Material Stainless Steel, Keyway Width Not Applicable, Collar Material Grade 303, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 1-Piece, Screw Material Stainless Steel
Additional Information
Country of Origin:
United States
Bore Dia.:
48 mm
Material:
303 Stainless Steel
Number of Pieces:
1
Collar Style:
Clamp
Outside Dia.:
78 mm
Dimension Type:
Metric
Width:
19 mm
Screw Size:
M8 x 25
Operating Temp. Range:
-40 Degrees to 350 Degrees F
Clearance Dia.:
84.7 mm
Screw Material:
Stainless Steel
Item:
Shaft Collar
Material - Collars:
303 Stainless Steel
System of Measurement:
Metric
Bore Type - Collars:
Plain Bore
Item - Shaft Collars:
Shaft Collar
Shaft Locking Type - Couplings:
1 Piece Clamp
Standards:
Conflict Minerals Compliant, DIN 912 12.9, ISO 9001
Distance Across Flats:
Not Applicable
Bore Tolerance:
+0.050/+0.012 mm
Screw Seating Torque:
23 N-m
Width Tolerance:
+0.076/-0.254 mm
Bore Type:
Round
Lever Height:
Not Applicable
Screw Thread Size:
M8x25
Resistance Properties:
Corrosion Resistant
Component Mount Type:
Not Applicable
Lever Part Number:
Not Applicable
Mount Hole Thread Size:
Not Applicable
Collar Material Finish:
Bright
Collar Construction:
1-Piece
Center to Lever Top:
Not Applicable
Flat to Bore:
Not Applicable
Thread Direction:
Not Applicable
Clearance Diameter:
84.7 mm
Bore Width:
Not Applicable
Collar Outside Diameter:
78 mm
Minimum Operating Temperature:
-40 Degrees C
Screw Length:
25 mm
Screw Location from Center:
32 mm
Lever Length:
Not Applicable
Collar Material:
Stainless Steel
Screw Material Grade:
304
Shaft Locking Type:
Clamp On
Bore Thread Size:
Not Applicable
Keyway Width:
Not Applicable
Collar Material Grade:
303
Maximum Operating Temperature:
176 Degrees C
For Shaft Diameter:
48 mm
Included Screws:
(1) Hex Socket Cap Screw
Screw Material Finish:
Bright
Inside Height to Flat:
Not Applicable
Keyway Depth:
Not Applicable
Handle Material Finish:
Not Applicable
Handle Color:
Not Applicable
Bore Diameter:
48 mm
Shaft Tolerance:
+0.000/-0.013 mm
Handle Material:
Not Applicable
Collar Width:
19 mm
Package Quantity:
1
