Shaft Collar, Clamp, 1Pc, 2 In, Steel - WCL-32-F

Shaft Collar, Clamp, 1Pc, 2 In, Steel - WCL-32-F

Ruland
SKU:
WCL-32-F
|
UPC:
634529136720
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Shaft Collar, System of Measurement Inch, Bore Type Round, Bore Diameter 2 in, Bore Thread Size Not Applicable, Collar Outside Diameter 3 in, Inside Height to Flat Not Applicable, Clearance Diameter 3.36 in, Collar Width 1 15/32 in, Collar Material Carbon Steel, Keyway Width Not Applicable, Collar Material Grade 1215, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 1-Piece, Screw Material Alloy Steel
Additional Information
Country of Origin:
United States
Bore Dia.:
2 in
Material:
Black Oxide 1215 Lead Free Steel
Number of Pieces:
1
Collar Style:
Clamp
Outside Dia.:
3 in
Dimension Type:
Inch
Width:
9 mm
Screw Size:
5/16-24"
Operating Temp. Range:
-40 Degrees to 350 Degrees F
Clearance Dia.:
20.8 mm
Screw Material:
Alloy Steel
Shaft Locking Type - Couplings:
1 Piece Clamp
Material - Collars:
Black Oxide 1215 Lead Free Steel
System of Measurement:
Inch
Item:
Shaft Collar
Item - Shaft Collars:
Shaft Collar
Bore Type - Collars:
Plain Bore
Standards:
ANSI, Conflict Minerals Compliant, ISO 9001
Screw Seating Torque:
325 lb-in
Bore Tolerance:
+0.002/+0.0005 in
Distance Across Flats:
Not Applicable
Width Tolerance:
+0.003/-0.010 in
Minimum Operating Temperature:
-40 Degrees F
Bore Thread Size:
Not Applicable
Collar Material:
Carbon Steel
Screw Thread Size:
5/16-24"
Lever Height:
Not Applicable
Lever Length:
Not Applicable
Handle Material Finish:
Not Applicable
Collar Outside Diameter:
3 in
Screw Material Finish:
Black Oxide
Bore Diameter:
2 in
Bore Width:
Not Applicable
Handle Material:
Not Applicable
Clearance Diameter:
3.36 in
Shaft Tolerance:
+0.0000/-0.0005 in
Collar Material Grade:
1215
Screw Location from Center:
1.25 in
Shaft Locking Type:
Clamp On
Mount Hole Thread Size:
Not Applicable
Handle Color:
Not Applicable
Keyway Depth:
Not Applicable
Inside Height to Flat:
Not Applicable
Center to Lever Top:
Not Applicable
Included Screws:
(2) Hex Socket Cap Screw
Bore Type:
Round
Maximum Operating Temperature:
350 Degrees F
For Shaft Diameter:
2 in
Component Mount Type:
Not Applicable
Thread Direction:
Not Applicable
Keyway Width:
Not Applicable
Lever Part Number:
Not Applicable
Flat to Bore:
Not Applicable
Resistance Properties:
Not Applicable
Collar Material Finish:
Black Oxide
Collar Construction:
1-Piece
Collar Width:
1 15/32 in
Package Quantity:
1
