Shaft Collar, Clamp, 1Pc, 2-13/16 In, 303 SS - CL-45-SS

Shaft Collar, Clamp, 1Pc, 2-13/16 In, 303 SS - CL-45-SS

Ruland
SKU:
CL-45-SS
|
UPC:
634529001172
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Shaft Collar, System of Measurement Inch, Bore Type Round, Bore Diameter 2 13/16 in, Bore Thread Size Not Applicable, Collar Outside Diameter 4 1/4 in, Inside Height to Flat Not Applicable, Clearance Diameter 4.5 in, Collar Width 7/8 in, Collar Material Stainless Steel, Keyway Width Not Applicable, Collar Material Grade 303, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 1-Piece, Screw Material Stainless Steel
Additional Information
Country of Origin:
United States
Bore Dia.:
2 13/16 in
Material:
303 Stainless Steel
Number of Pieces:
1
Collar Style:
Clamp
Outside Dia.:
4 1/4 in
Dimension Type:
Inch
Width:
7/8 in
Screw Size:
3/8-24"
Operating Temp. Range:
-40 Degrees to 350 Degrees F
Clearance Dia.:
4.499 in
Screw Material:
Stainless Steel
Shaft Locking Type - Couplings:
1 Piece Clamp
Item:
Shaft Collar
Item - Shaft Collars:
Shaft Collar
System of Measurement:
Inch
Material - Collars:
303 Stainless Steel
Standards:
ANSI, Conflict Minerals Compliant, ISO 9001
Bore Type - Collars:
Plain Bore
Distance Across Flats:
Not Applicable
Width Tolerance:
+0.003/-0.010 in
Bore Tolerance:
+0.002/+0.0005 in
Screw Seating Torque:
345 lb-in
Handle Material Finish:
Not Applicable
Lever Length:
Not Applicable
Collar Material Finish:
Bright
Collar Material Grade:
303
Clearance Diameter:
4.5 in
Shaft Locking Type:
Clamp On
Bore Diameter:
2 13/16 in
Lever Part Number:
Not Applicable
Keyway Depth:
Not Applicable
Screw Material Finish:
Bright
Component Mount Type:
Not Applicable
Resistance Properties:
Corrosion Resistant
Minimum Operating Temperature:
-40 Degrees F
Lever Height:
Not Applicable
For Shaft Diameter:
2 13/16 in
Maximum Operating Temperature:
350 Degrees F
Handle Material:
Not Applicable
Keyway Width:
Not Applicable
Inside Height to Flat:
Not Applicable
Collar Construction:
1-Piece
Collar Material:
Stainless Steel
Shaft Tolerance:
+0.0000/-0.0005 in
Center to Lever Top:
Not Applicable
Bore Type:
Round
Flat to Bore:
Not Applicable
Screw Material Grade:
304
Included Screws:
(1) Hex Socket Cap Screw
Collar Outside Diameter:
4 1/4 in
Bore Thread Size:
Not Applicable
Mount Hole Thread Size:
Not Applicable
Thread Direction:
Not Applicable
Screw Location from Center:
1.81 in
Bore Width:
Not Applicable
Screw Thread Size:
3/8-24"
Handle Color:
Not Applicable
Collar Width:
7/8 in
Package Quantity:
1
