Safety Relief Valve, 2 In, 100 psi, Bronze - 1060820

Safety Relief Valve, 2 In, 100 psi, Bronze - 1060820

Apollo Valves
SKU:
1060820
|
UPC:
670750879623
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Safety Relief Valve, Body Material Bronze, Inlet Type FNPT, Outlet Type FNPT, Inlet Size 2 in, Outlet Size 2 in, Factory Set Pressure 100 psig, Pressure Range 15 to 160 psi, 13,577,000 BtuH BtuH, Disc Material Brass, Overall Height 5 5/8 in, Application Heating, Overall Length 9 1/2 in, Seat Material Silicone, Spring Material Alloy Steel, Temp. Range 0 Degrees to 250 Degrees F, Test Lever Test Lever Included
Additional Information
Country of Origin:
United States
Inlet Size:
2";Outlet Size=2""
Body Material:
Bronze
Item:
Safety Relief Valve
Outlet Type:
FNPT
Inlet Type:
FNPT
Overall Height:
14 in
Factory Set Pressure:
100 psi
Standards:
ASME Section IV, CRN, CSA
Temp. Range:
0 Degrees to 250 Degrees F
Overall Length:
7 3/16 in
Seat Material:
Silicone
Test Lever:
Yes
Application:
Hot Water Heating Boilers and Hot Water Supply Systems
Pressure Range:
15 to 160 psi
Spring Material:
Plated Alloy Steel
Disc Material:
Brass ASTM B16
BtuH:
13,577,000
Product Type:
Safety Relief Valve
Operating Pressure - Maximum:
174 psi
For Media:
Water
Inlet Connection Type:
NPT
Inlet Connection Size:
2 in
Outlet Connection Size:
2 in
Outlet Connection Gender:
Female
Outlet Connection Type:
NPT
Operating Temperature - Maximum:
249.8 Degrees F
ASME Section Code:
Section IV
Operating Temperature - Minimum:
32 Degrees F
Operating Pressure - Minimum:
30 psi
Inlet Connection Gender:
Female
Package Quantity:
1
