Pwr Dist Block, 310A, 2P, 6AWG-350 MCM, 600V - 9080LBA263101

Pwr Dist Block, 310A, 2P, 6AWG-350 MCM, 600V - 9080LBA263101

Square D
SKU:
9080LBA263101
|
UPC:
785901156987
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Power Distribution Block, For Conductor Material Aluminum, Copper, Line Connections/Pole 1, For Line Copper Wire Size - Minimum 6 AWG, For Line Copper Wire Size - Maximum 350 kcmil, Load Connections/Pole 1, For Load Copper Wire Size - Minimum 6 AWG, For Load Copper Wire Size - Maximum 350 kcmil, Maximum Current - Copper Conductor 310 A, Maximum Voltage 600 V AC/DC, Mounting Type Surface Mount, Number of Poles 2, Overall Depth 2.61 in, Overall Length 3.38 in, Overall Width 1.94 in
Additional Information
Country of Origin:
United States
Item:
Power Distribution Block
Number of Poles:
2
Max. Amps:
310 A
Primary Connections/Pole:
1
Primary Wire Range (AWG):
6 AWG to 350 MCM
Secondary Connection/Pole:
1
Secondary Wire Range (AWG):
6 AWG to 350 MCM
Power Distribution Block Design:
Open
Voltage Rating:
600V AC
Depth:
2.61 in
Width:
3.47 in
Standards:
CE Marked, CSA File 70361 Class 6228-1, UL File E60616 Guide XCFR2
Length:
13.4 in
Length (Straight Wireway):
13.4 in
For Load Copper Wire Size - Minimum:
6 AWG
Line Connections/Pole:
1
Special Features:
18 Months Warranty, Surface Mount
For Load Copper Wire Size - Maximum:
350 kcmil
Terminal Material:
Aluminum
For Conductor Material:
Aluminum, Copper
Overall Width:
1.94 in
Maximum Current - Copper Conductor:
310 A
For Line Copper Wire Size - Maximum:
350 kcmil
RoHS Compliant:
Yes
For Line Aluminum Wire Size - Minimum:
6 AWG
Overall Depth:
2.61 in
Maximum Operating Temperature:
302 Degrees F
Overall Length:
3.38 in
Primary Wire Range:
6 AWG to 350 kcmil
For Line Aluminum Wire Size - Maximum:
350 kcmil
Housing Material:
Phenolic
For Line Copper Wire Size - Minimum:
6 AWG
For Load Aluminum Wire Size - Minimum:
6 AWG
Minimum Operating Temperature:
-40 Degrees F
Maximum Voltage:
600 V AC/DC
Line Side Connection Type:
Lug
Load Connections/Pole:
1
Housing Color:
Black
Maximum Current - Aluminum Conductor:
250 A
Number of Circuits:
2
Secondary Wire Range:
6 AWG to 350 MCM
For Load Aluminum Wire Size - Maximum:
350 kcmil
Load Side Connection Type:
Lug
Mounting:
Surface Mount
Amps:
Al conductor
Min. Operating Temp.:
-40°F
Max. Operating Temp.:
302°F
Features:
Mercury Free
Electrical Connection:
Tin plated Aluminium Lugs
Material:
Phenolic
Wire Strip Length:
Line 1.06 in; Load 1.06 in
Package Quantity:
1
