Push Button with Transmitter, 22 mm, White - ZB5RTA1

Push Button with Transmitter, 22 mm, White - ZB5RTA1

Schneider Electric
SKU:
ZB5RTA1
|
UPC:
785901919100
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Wireless Push Button Transmitter, Color White, Action Momentary, Material Plastic, NEMA Rating 12, IP Rating IP30, Number of Operators 1, Size 22 mm, Type of Operator Flush Push Button, Height 1.3 in, Width 3.39 in, Length 2.05 in, Legend Markings No Legend, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Additional Information
Country of Origin:
France
Action:
Momentary
Size:
22 mm
Head Material:
Plastic
NEMA Rating:
12
Type of Operator:
Flush Push Button
Color:
White
Legend:
None
Number of Operators:
1
Item:
Wireless Push Button Transmitter
Bezel Material:
dark grey plastic
Height:
1.3 in
IP Rating:
IP30
Width:
3.39 in
Standards:
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Length:
2.05 in
Material:
Plastic
Legend Markings:
No Legend
Series:
XB5R
Length (Straight Wireway):
2.05 in
Emission Power:
3 mW
Embedding Depth:
42 mm
Shape Of Signaling Unit Head:
round
Number Of Channels:
16
Operating Travel:
4.3 mm total travel)
Fixing Collar Material:
plastic
Device Short Name:
XB5R
Mounting Diameter:
22 mm
Ip Degree Of Protection:
IP66 IEC 60529 front face) || IP67 IEC 60529 front face) || IP69 IEC 60529 front face) || IP69K IEC 60529 front face)
Modulation Technique:
O-QPSK
Shock Resistance:
25 gn 6 ms) 6000 shocks IEC 60068-2-27 || 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Mechanical Durability:
1000000 cycles
Cad Overall Depth:
43 mm
Antenna Gain:
0 dBi
Electromagnetic Compatibility:
electrostatic discharge immunity test 8 kV in free air (in insulating parts)) IEC 61000-4-2 || electrostatic discharge immunity test 4 kV on contact (on metal parts)) IEC 61000-4-2 || susceptibility to electromagnetic fields 20 V/m 80 to 3000 MHz) IE
Product Or Component Type:
wireless and batteryless transmitter
Fixing Mode:
fixing nut beneath head 2-2.4 N.m
Station Name:
XALD 1 to 5 cut-outs || XALK 2 to 5 cut-outs
Communication Port Protocol:
Zigbee green power 2.4 GHz IEEE 802.15.4
Level Or Class:
5M00G7W
Relative Humidity:
95-95 % -40-70°C without condensation
Mechanical Robustness:
free fall resistance 1000 mm EN/IEC 60068-2-32
Acquisition Time:
2 ms
Transmission Frequency:
2405 MHz
Operator Profile:
white flush
Bandwidth:
5-5 MHz
Operating Force:
10 N C/O changing electrical state
Radio Agreement:
ANATEL || ARIB T66 || FCC || ICASA || RSS
Ambient Air Temperature For Storage:
-40-70°C
Max Power Consumption In W:
1 mW
Maximum Sensing Distance:
100 m in free field || 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure || 300 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna
Ambient Air Temperature For Operation:
-40-70°C
Electrical Composition Code:
PW1
Antenna Type:
omnidirectional
Product Certifications:
CSA || C-tick || GOST || BT 2006/95/EC || UL || CCC
Vibration Resistance:
5 gn 11-500 Hz)IEC 60068-2-6 || +/- 10 mm 2-11 Hz)IEC 60068-2-6
Response Time:
< 2 ms
Cad Overall Height:
41.5 mm
Ik Degree Of Protection:
IK03 IEC 50102
Cad Overall Width:
30 mm
Operating Temperature - Maximum:
158 Degrees F
Head Color:
White
Overall Height:
1.62 in
Operating Temperature - Minimum:
-40 Degrees F
NEMA Enclosure Rating:
12
Mechanical Operating Durability:
1,000,000
Legend Color:
Not Applicable
Legend Background Color:
Not Applicable
Panel Cutout Diameter:
22 mm
Push Button Style:
Flush
Resistance Properties:
Shock Resistant, Vibration Resistant
Overall Width:
1.17 in
Manufacturer Warranty Length:
18 mo
Operator Material:
Plastic
Overall Depth:
2.05 in
Mushroom Head Diameter:
Not Applicable
Operator Illumination:
Non-Illuminated
Maintained Action Release:
Not Applicable
Package Quantity:
1
