Push Button with Transmitter, 22 mm, Green - ZB4RTA3

Push Button with Transmitter, 22 mm, Green - ZB4RTA3

Schneider Electric
SKU:
ZB4RTA3
|
UPC:
785901705352
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Wireless Push Button Transmitter, Color Green, Action Momentary, Material Metal, NEMA Rating 12, IP Rating IP30, Number of Operators 1, Size 22 mm, Type of Operator Flush Push Button, Height 1.3 in, Width 3.39 in, Length 2.05 in, Legend Markings No Legend, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Additional Information
Country of Origin:
France
Action:
Momentary
Size:
22 mm
Head Material:
Metal
NEMA Rating:
12
Type of Operator:
Flush Push Button
Color:
Green
Legend:
None
Number of Operators:
1
Item:
Wireless Push Button Transmitter
Bezel Material:
chromium plated metal
Legend Markings:
No Legend
IP Rating:
IP30
Material:
Metal
Height:
1.3 in
Width:
3.39 in
Standards:
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Length:
2.05 in
Series:
XB4R
Length (Straight Wireway):
2.05 in
Product Certifications:
BT 2006/95/EC || C-tick || CCC || UL || GOST || CSA
Operator Profile:
green flush
Mechanical Durability:
1000000 cycles
Level Or Class:
5M00G7W
Fixing Mode:
fixing screw beneath head 0.8-1.2 N.m
Electromagnetic Compatibility:
electrostatic discharge immunity test 8 kV in free air (in insulating parts)) IEC 61000-4-2 || electrostatic discharge immunity test 4 kV on contact (on metal parts)) IEC 61000-4-2 || susceptibility to electromagnetic fields 20 V/m 80 to 3000 MHz) IE
Shape Of Signaling Unit Head:
round
Cad Overall Height:
41.5 mm
Protective Treatment:
TH
Number Of Channels:
16
Fixing Collar Material:
zamak
Mounting Diameter:
22 mm
Radio Agreement:
ANATEL || ARIB T66 || FCC || ICASA || RSS
Cad Overall Depth:
43 mm
Modulation Technique:
O-QPSK
Operating Force:
10 N C/O changing electrical state
Max Power Consumption In W:
1 mW
Ik Degree Of Protection:
IK03 IEC 50102
Bandwidth:
5-5 MHz
Cad Overall Width:
30 mm
Response Time:
< 2 ms
Antenna Type:
omnidirectional
Embedding Depth:
42 mm
Ambient Air Temperature For Operation:
-40-70°C
Device Short Name:
XB5R
Antenna Gain:
0 dBi
Ambient Air Temperature For Storage:
-40-70°C
Communication Port Protocol:
Zigbee green power 2.4 GHz IEEE 802.15.4
Relative Humidity:
95-95 % -40-70°C without condensation
Maximum Sensing Distance:
100 m in free field || 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure || 300 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna
Shock Resistance:
25 gn 6 ms) 6000 shocks IEC 60068-2-27 || 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Product Or Component Type:
wireless and batteryless transmitter
Ip Degree Of Protection:
IP66 IEC 60529 front face) || IP67 IEC 60529 front face) || IP69 IEC 60529 front face) || IP69K IEC 60529 front face)
Operating Travel:
4.3 mm total travel)
Emission Power:
3 mW
Transmission Frequency:
2405 MHz
Mechanical Robustness:
free fall resistance 1000 mm EN/IEC 60068-2-32
Acquisition Time:
2 ms
Electrical Composition Code:
PW1
Vibration Resistance:
5 gn 11-500 Hz)IEC 60068-2-6 || +/- 10 mm 2-11 Hz)IEC 60068-2-6
Operator Illumination:
Non-Illuminated
Head Color:
Green
Manufacturer Warranty Length:
18 mo
Panel Cutout Diameter:
22 mm
Mechanical Operating Durability:
1,000,000
Maintained Action Release:
Not Applicable
NEMA Enclosure Rating:
12
Overall Depth:
2.05 in
Legend Color:
Not Applicable
Operating Temperature - Minimum:
-40 Degrees F
Legend Background Color:
Not Applicable
Overall Height:
1.82 in
Operator Material:
Metal
Resistance Properties:
Shock Resistant, Vibration Resistant
Mushroom Head Diameter:
Not Applicable
Overall Width:
1.18 in
Push Button Style:
Flush
Operating Temperature - Maximum:
158 Degrees F
Package Quantity:
1
