Push Button with Transmitter, 22 mm, Black - ZB5RTA2

Push Button with Transmitter, 22 mm, Black - ZB5RTA2

Schneider Electric
SKU:
ZB5RTA2
|
UPC:
785901694793
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Wireless Push Button Transmitter, Color Black, Action Momentary, Material Plastic, NEMA Rating 12, IP Rating IP30, Number of Operators 1, Size 22 mm, Type of Operator Flush Push Button, Height 1.3 in, Width 3.39 in, Length 2.05 in, Legend Markings No Legend, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
Additional Information
Country of Origin:
France
Action:
Momentary
Size:
22 mm
Head Material:
Plastic
NEMA Rating:
12
Type of Operator:
Flush Push Button
Color:
Black
Legend:
None
Number of Operators:
1
Item:
Wireless Push Button Transmitter
Bezel Material:
dark grey plastic
Height:
1.3 in
Legend Markings:
No Legend
Length:
2.05 in
Width:
3.39 in
Standards:
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508
IP Rating:
IP30
Material:
Plastic
Series:
XB5R
Length (Straight Wireway):
2.05 in
Mechanical Robustness:
free fall resistance 1000 mm EN/IEC 60068-2-32
Product Certifications:
BT 2006/95/EC || C-tick || CSA || UL || CCC || GOST
Electrical Composition Code:
PW1
Station Name:
XALD 1 to 5 cut-outs || XALK 2 to 5 cut-outs
Bandwidth:
5-5 MHz
Product Or Component Type:
wireless and batteryless transmitter
Level Or Class:
5M00G7W
Operator Profile:
black flush
Antenna Gain:
0 dBi
Embedding Depth:
42 mm
Acquisition Time:
2 ms
Ambient Air Temperature For Operation:
-40-70°C
Response Time:
< 2 ms
Transmission Frequency:
2405 MHz
Fixing Collar Material:
plastic
Ik Degree Of Protection:
IK03 IEC 50102
Operating Travel:
4.3 mm total travel)
Relative Humidity:
95-95 % -40-70°C without condensation
Fixing Mode:
fixing nut beneath head 2-2.4 N.m
Operating Force:
10 N C/O changing electrical state
Shock Resistance:
25 gn 6 ms) 6000 shocks IEC 60068-2-27 || 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Antenna Type:
omnidirectional
Emission Power:
3 mW
Max Power Consumption In W:
1 mW
Device Short Name:
XB5R
Vibration Resistance:
5 gn 11-500 Hz)IEC 60068-2-6 || +/- 10 mm 2-11 Hz)IEC 60068-2-6
Cad Overall Height:
41.5 mm
Number Of Channels:
16
Communication Port Protocol:
Zigbee green power 2.4 GHz IEEE 802.15.4
Modulation Technique:
O-QPSK
Ip Degree Of Protection:
IP66 IEC 60529 front face) || IP67 IEC 60529 front face) || IP69 IEC 60529 front face) || IP69K IEC 60529 front face)
Cad Overall Width:
30 mm
Shape Of Signaling Unit Head:
round
Maximum Sensing Distance:
100 m in free field || 25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure || 300 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna
Mechanical Durability:
1000000 cycles
Cad Overall Depth:
43 mm
Radio Agreement:
ANATEL || ARIB T66 || FCC || ICASA || RSS
Ambient Air Temperature For Storage:
-40-70°C
Electromagnetic Compatibility:
electrostatic discharge immunity test 8 kV in free air (in insulating parts)) IEC 61000-4-2 || electrostatic discharge immunity test 4 kV on contact (on metal parts)) IEC 61000-4-2 || susceptibility to electromagnetic fields 20 V/m 80 to 3000 MHz) IE
Mounting Diameter:
22 mm
Legend Background Color:
Not Applicable
Maintained Action Release:
Not Applicable
Operator Illumination:
Non-Illuminated
Push Button Style:
Flush
Overall Height:
1.62 in
Operating Temperature - Maximum:
158 Degrees F
Legend Color:
Not Applicable
Panel Cutout Diameter:
22 mm
Mushroom Head Diameter:
Not Applicable
Head Color:
Black
NEMA Enclosure Rating:
12
Overall Depth:
2.05 in
Operator Material:
Plastic
Manufacturer Warranty Length:
18 mo
Mechanical Operating Durability:
1,000,000
Resistance Properties:
Shock Resistant, Vibration Resistant
Overall Width:
1.17 in
Operating Temperature - Minimum:
-40 Degrees F
Package Quantity:
1
