Push Buttn Cntrl Station, Start/Stop, 30mm - 9001BW240

Push Buttn Cntrl Station, Start/Stop, 30mm - 9001BW240

Square D
SKU:
9001BW240
|
UPC:
785901458753
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Control Station, Number of Operators 2, Number of Pilot Lights 0, Size 30 mm, Legend Start/Stop, Type of Operator Push Button/Push Button, Action Momentary/Momentary, Operator Color Black, Red, Contact Form 1NO/1NC, Mechanical Interlock No, NEMA Rating 4, Contact Rating 5A @ 600V AC/24V DC, IP Rating IP66, Mounting Wall, Hub 1/2 in NPT, Height 3.6 in, Width 2.76 in, Depth 4.25 in, Enclosure Material Zinc, Enclosure Color Gray, Standards CE, CSA LR25490 Class 3211 03, UL E42259 CCN NKCR
Additional Information
Country of Origin:
Mexico
Item:
Control Station
Contact Form:
1NO/1NC
Number of Gangs:
1
Legend:
Start/Stop
Type of Operator:
Push Button/Push Button
Number of Pilot Lights:
0
Number of Operators:
2
NEMA Rating:
4
Hub Style:
Dead-End
Series:
9001
Size:
30 mm
Standards:
CE, CSA LR25490 Class 3211 03, UL E42259 CCN NKCR
Contact Rating:
5A @ 600V AC/24V DC
For Use With:
indoor/outdoor
Action:
Momentary/Momentary
Hub:
1/2 in NPT
Mechanical Interlock:
No
Height:
3.6 in
Width:
2.76 in
Enclosure Material:
Zinc
Green Environmental Attribute:
RoHS 2011/65/EU Compliant
IP Rating:
IP66
Mounting:
Wall
Depth:
4.25 in
Operator Color:
Black, Red
Enclosure Color:
Gray
Number of Speeds:
1
Terminal Connection:
screw clamp terminal
Mounting Style:
Surface
Product Or Component Type:
Complete control station
Control Station Composition:
2 push-buttons START-STOP
Rated Operational Current:
5 A 600 V
Product Certifications:
CE; CSA LR25490 class 3211 03; UL listed file E42259 CCN NKCR
Device Mounting:
Surface
NEMA Degree Of Protection:
NEMA 4
Environmental Characteristic:
Dust and damp proof
Contact Type and Composition:
1 NO + 1 NC
Overall Depth:
4.25 in
Operator Configuration:
(2) Push Buttons
Operating Temperature - Maximum:
158 Degrees F
Maintained Action Release:
Not Applicable
Hazardous Location Specification:
Not Rated
Operating Temperature - Minimum:
-13 Degrees F
Hub Size - Maximum:
1/2 in
Manufacturer Warranty Length:
18 mo
AC Contact Rating:
0.6 A @ 600 V, 0.75 A @ 480 V, 1.5 A @ 240 V, 3.75 A @ 120 V
Includes Mechanical Interlock:
No Mechanical Interlock Included.
Product Type:
Control Station
Pilot Light Color:
Not Applicable
DC Contact Rating:
0.2 A @ 600 V, 0.55 A @ 240 V, 1.1 A @ 120 V
Overall Width:
2.76 in
Overall Height:
3.6 in
Selector Switch Number of Positions:
Not Applicable
NEMA Enclosure Rating:
4
Mounting Orientation:
Not Applicable
Panel Cutout Diameter:
Not Applicable
Package Quantity:
1
