Proximity Sensor, Inductive, 8mm, NO - IG0307

Proximity Sensor, Inductive, 8mm, NO - IG0307

Ifm
SKU:
IG0307
|
UPC:
94720804024
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Inductive Cylindrical Proximity Sensor, Inductive, 18 mm, Proximity Sensor Power Requirement 20 to 250V AC/DC, Unshielded, Proximity Sensor Operating Frequency 25 Hz AC/50 Hz DC, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 8 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NO, IP Rating IP67, Case Material Brass White Bronze Coated, Length 98 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 250/100mA
Additional Information
Country of Origin:
Romania
Item:
Inductive Cylindrical Proximity Sensor
Proximity Sensor Style:
Cylindrical Proximity Sensor
Proximity Sensing Method:
Inductive
Proximity Sensor Power Requirement:
20 to 250V AC/DC
Proximity Sensor Output Circuit Type:
2 Wire
Output Mode:
NO
Length:
98 mm
Proximity Sensor Diameter:
18 mm
Max. Detecting Distance:
8 mm
Proximity Sensor Electrical Connection:
2m Cable
Basic Proximity Sensor Case Material:
Metal
Shielded / Unshielded:
Unshielded
Proximity Sensor Operating Frequency:
25 Hz AC/50 Hz DC
Case Material:
Brass White Bronze Coated
IP Rating:
IP67
Includes:
(2) Lock Nuts
Operating Temp. Range:
-13 Degrees to 158 Degrees F
Max. Current Load:
250/100mA
Standards:
EN 61000-4-2 ESD, EN 55011, EN 61000-4-3 HF Radiated, EN 61000-4-4 Burst, EN 61000-4-6 HF Conducted, UL E174191, UL Listed
Description/Special Features:
Red LED Output Indication
Electrical Connection:
Bare Wire
Length (Straight Wireway):
98 mm
Max. voltage drop switching output AC [V]:
6.5
Minimum load current [mA]:
5
Max. voltage drop switching output DC [V]:
6
Permanent current rating of switching output AC [mA]:
250; (350 (...50°C))
Switching frequency DC [Hz]:
50
Sensing range [mm]:
8
Max. leakage current [mA]:
2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC)
Protection:
IP 67
Connection:
Cable
EMC:
EN 61000-4-2 ESD 4 kV CD / 8 kV AD EN 61000-4-3 HF radiated 10 V/m EN 61000-4-4 Burst 2 kV EN 61000-4-6 HF conducted 10 V EN 55011 class B
Housing:
threaded type
Dimensions [mm]:
M18 x 1 / L = 80
Operating distance [mm]:
0...6.5
MTTF [years]:
604
Tightening torque [Nm]:
23
Reverse polarity protection:
no
Items supplied:
lock nuts
Thread designation:
M18 x 1
Required protection:
miniature fuse to IEC60127-2 sheet 1; ≤2 A; fast acting
Short-circuit proof:
no
Materials:
brass white bronze coated; sensing face
Permanent current rating of switching output DC [mA]:
100
Ambient temperature [°C]:
-25...80
Display:
switching status 1 x LED, red
Correction factor:
steel
Real sensing range Sr [mm]:
8± 10 %
Mounting:
non-flush mountable
Hysteresis [% of Sr]:
1...15
Overload protection:
no
UL approval:
Ta 0...40°C Enclosure type Type 1 power supply Hazardous voltage File number UL E174191
Output function:
normally open
Switching frequency AC [Hz]:
25
Operating voltage [V]:
20...250 AC/DC
Switch point drift [% of Sr]:
-10...10
Protection class:
II
Short-time current rating of switching output [mA]:
2200; (20 ms / 0,5 Hz)
Ambient temperature [°C]:
-25...80
Style:
Cylindrical
Electrical Installation Type:
Prewired Cable
Sensing Distance - Maximum:
8 mm
Ring Inside Diameter:
Not Applicable
Output Circuit Type:
AC/DC-Type
Output Circuit Number of Wires:
2
Sensing Method:
Inductive
Switching Frequency:
25 Hz (AC), 50 Hz (DC)
Output Circuit Contact Form:
NO
AC Voltage Rating:
20-250V AC
Body Finish:
Bronze Coated
Output Circuit Current - Maximum:
250 mA
Overall Width:
Not Applicable
Output Circuit Voltage - Maximum:
6 V DC
Operating Temperature - Maximum:
176 Degrees F
Operating Temperature - Minimum:
-13 Degrees F
Sensing Face Shielding:
Unshielded
Overall Depth:
Not Applicable
Body Material:
Brass
Overall Diameter:
18 mm
Resolution of Steel Ball Diameter:
Not Applicable
DC Voltage Rating:
20-250V DC
Cable Length:
2 m
Includes Indicator Lights:
Indicator Lights Included
Overall Height:
80 mm
Package Quantity:
1
