Proximity Sensor, Inductive, 30mm, NO - E57SAL30A4

Proximity Sensor, Inductive, 30mm, NO - E57SAL30A4

Eaton
SKU:
E57SAL30A4
|
UPC:
782113685489
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Inductive Cylindrical Proximity Sensor, Inductive, 30 mm, Proximity Sensor Power Requirement 40 to 250V AC, Shielded, Proximity Sensor Operating Frequency 20 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 10 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NO, NEMA Rating 12, 13, 4, 4X, 6, 6P, IP Rating IP67, Case Material Stainless Steel, Length 40 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 500mA
Additional Information
Country of Origin:
Mexico
Item:
Inductive Cylindrical Proximity Sensor
Proximity Sensor Style:
Cylindrical Proximity Sensor
Proximity Sensing Method:
Inductive
Proximity Sensor Power Requirement:
40 to 250V AC
Proximity Sensor Output Circuit Type:
2 Wire
Output Mode:
NO
Length:
40 mm
Proximity Sensor Diameter:
30 mm
Width:
1.18 in
Max. Detecting Distance:
10 mm
Depth:
1.58 in
Proximity Sensor Electrical Connection:
2m Cable
Basic Proximity Sensor Case Material:
Metal
Shielded / Unshielded:
Shielded
Proximity Sensor Operating Frequency:
20 Hz
Case Material:
Stainless Steel
Standards:
CE, CSA, UL Listed
NEMA Rating:
12, 13, 4, 4X, 6, 6P
IP Rating:
IP67
Max. Current Load:
500mA
Description/Special Features:
360 Degrees Viewable LED Output Indication, Overload and Short-Circuit Protection
Operating Temp. Range:
-13 Degrees to 158 Degrees F
Electrical Connection:
Bare Wire
Length (Straight Wireway):
40 mm
Body Type:
Short
Series:
E57
Maximum AC Current:
250 mA
Cable Type:
Polyvinyl Chloride (PVC)
Environmental Rating:
NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP67
Cord Length:
79.2 ft
Operating Temperature - Max:
158 °F
Certifications:
UL Listed;CSA Certified
Operating Temperature - Min:
-13 °F
Type:
Short Barrel Inductive Proximity Premium+ Sensor
Led Indicator:
360° viewable LED
Product Name:
Eaton E57 inductive proximity sensor
Input Voltage:
20-250 V
Accuracy:
< 3% sensing range
Contact Rating:
250 mA at 250V
Compliances:
CE Marked
Contact Configuration:
2-wire AC, NO
Protection:
Resettable short circuit, overload
Output Circuit Number of Wires:
2
Sensing Face Shielding:
Shielded
NEMA Enclosure Rating:
12, 13, 4, 4X, 6, 6P
Electrical Installation Type:
Prewired Cable
Ring Inside Diameter:
Not Applicable
Sensing Method:
Inductive
AC Voltage Rating:
20-250V AC
Overall Width:
Not Applicable
Sensing Distance - Maximum:
10 mm
Body Material:
Stainless Steel
Cable Length:
2 m
Features:
360 Degree LED Indicator, Overload Protection, Resettable Short Circuit
Output Circuit Contact Form:
NO
Switching Frequency:
20 Hz
Load Current - Maximum:
250 mA
Overall Depth:
Not Applicable
DC Voltage Rating:
Not Rated
Resolution of Steel Ball Diameter:
Not Applicable
Includes Indicator Lights:
Indicator Lights Included
Output Circuit Type:
AC-Type
Operating Temperature - Minimum:
-13 Degrees F
Style:
Cylindrical
Overall Height:
69 mm
Operating Temperature - Maximum:
158 Degrees F
Overall Diameter:
30 mm
Package Quantity:
1
