Portable Flux Core Welder, Easy Core 125 Series, 120VAC - K2696-1

Portable Flux Core Welder, Easy Core 125 Series, 120VAC - K2696-1

Lincoln Electric
SKU:
K2696-1
|
UPC:
15082689661
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Flux-Cored Welder, Series Easy-Core 125, Input Voltage 120V AC, Phase Single-Phase, Welding Mode CV, Polarity DC, Input Frequency 60 Hz, Welding Processes Flux-Cored Welding (FCAW), For Wire Type Flux-Cored, Maximum Wire Diameter 0.035 in (Flux-Cored), Maximum Wire Feed Speed 500 in/min, Model K2696-1, MIG Welding Output @ Duty Cycle 90 A @ 19 V, 20 Percent
Additional Information
Country of Origin:
Mexico
Item:
Flux-Cored Welder
Input Voltage:
120V AC
Series:
Easy-Core 125
Overall Width:
10.15 in
Application:
Farm, Home, Shop
Welding Processes:
Flux-Cored Welding (FCAW)
Features:
Precise Wire Drive, Spool Gun Ready, No Hassle Tool-less Design, Innovative Contact Tip, Drive Roll and Nozzle Storage
Standards:
CSA Certified
Includes:
(3) 0.035 in Contact Tips, 0.030 in 0.045 in Drive Roll for Flux-Core, Gasless Nozzle, Magnum 100L gun and 10 ft cable assembly with brass gun connection and 4-pin MS-Type connection for trigger control (K530-6), Sample spool of 0.035 in. diameter In
Input Amps:
20
Duty Cycle:
20 %
Wire Size:
0.025 in to 0.030 in, Flux 0.030 in to 0.035 in
Overall Depth:
17.9 in
Mild Steel - Material Thickness:
20 ga to 5/16 in
Phase:
Single-Phase
Rated Output:
90A @ 19V DC
Portability:
Handheld Portable
Welded Material:
Mild Steel
Overall Height:
13.7 in
Output Range:
30 to 125A DC
Hz:
60
Minimum Wire Diameter:
0.030 in (Flux-Cored)
Maximum Wire Diameter:
0.035 in (Flux-Cored)
Minimum Wire Feed Speed:
50 in/min
MIG Welding Maximum Output Current:
125 A
Plug Type:
5-15P
Input Frequency:
60 Hz
MIG Welding Output @ Duty Cycle:
90 A @ 19 V, 20%
For Minimum Material Thickness:
18 ga (Steel)
Color:
Red
For Maximum Material Thickness:
5/16 in (Steel)
Maximum Wire Feed Speed:
500 in/min
Weight:
49 lb
Welding Mode:
CV
Amperage Range:
30 to 125 A
For Material Type:
Mild Steel
Polarity:
DC
For Wire Type:
Flux-Cored
MIG Welding Minimum Output Current:
30 A
Model:
K2696-1
Package Quantity:
1
