Plug - HBL4200PS2W
HubbellLog in for pricing
(No reviews yet)
Write a Review
Hubbell
Plug - HBL4200PS2W
Pin and Sleeve Plug, Current Rating 200 A, Housing Color Black, Gray, IP Rating Not Rated, Number of Poles 3, Number of Wires 4, Voltage Rating 250V DC, 600V AC, Wire Connection Type Screw Terminals, Cap Type No Cap or Cover, Connection Orientation Straight, For Maximum Cable Diameter 2.5 in, For Minimum Cable Diameter 1 in, Grounding Grounded, Grounding Style Style 2, Housing Material Composite, Maximum Wire Size 250 kcmil, Minimum Wire Size 1 AWG, NEMA Enclosure Rating 4X
- Country of Origin:
- United States
- Item - Plugs and Receptacles:
- Watertight Pin and Sleeve Plug
- Amps - Plugs and Receptacles:
- 200A
- Number of Poles:
- 3
- Number of Wires:
- 4
- Switch Rated:
- No
- Grounding Style:
- Style 2
- Item:
- Pin and Sleeve Plug
- Features:
- All-Brass Sleeve Contacts Provide Reliable Electrical Contact, Catalog Number and Rating Visible While in Use, Locking Ring Provides UL Type 4X Watertight, Dust-Tight Seal
- Standards:
- CSA C22.2 No. 159, CSA Certified, UL 1010, UL 1682, UL 50, UL Listed
- For Minimum Cable Diameter:
- 1 in
- Wire Connection Type:
- Screw Terminals
- Minimum Wire Size:
- 1 AWG
- Cap Type:
- No Cap or Cover
- NEMA Enclosure Rating:
- 4X
- Reverse Service:
- No
- Maximum Operating Temperature:
- 75 Degrees C
- Voltage Rating:
- 250V DC, 600V AC
- Resistance Properties:
- Impact Resistant, Moisture Resistant, Watertight
- Maximum Wire Size:
- 250 kcmil
- Power Indicating Light:
- No
- IP Rating:
- Not Rated
- Grounding:
- Grounded
- Outside Diameter:
- 6.7 in
- For Maximum Cable Diameter:
- 2.5 in
- Connection Orientation:
- Straight
- Housing Material:
- Non-Metallic
- Minimum Operating Temperature:
- -40 Degrees C
- Market:
- Industrial
- UL 94 Flammability Rating:
- V-0
- Current Rating:
- 200 A
- Overall Length:
- 11.13 in
- Housing Color:
- Black, Gray
- Shrouded:
- Yes
- Max. Voltage:
- 600V
- Material:
- Composite
- Type:
- Watertight Plug
- Hub Style:
- Standard
- OEM Brand Name:
- Hubbell Wiring Device-Kellems
- Wire Size:
- #1 AWG to #250MCM
- Connectivity:
- Pressure Terminal Screws
- Style:
- Standard Service,Style 2 Grounding
- Display Size:
- Standard Sized
- Series:
- UL 1686 Class 1 Insulgrip®
- Voltage Rating Description:
- 600V AC/250V DC
- Environmental Conditions:
- Watertight
- Performance:
- Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 3,000V AC Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability (Enclosure) - UL 94V-0 an
- Nema Rating:
- Non-NEMA
- Industry Standard(s):
- CSA Certified to CSA Spec. C22.2 No. 159 UL Listed and CSA Certified Type 4X UL Standard 1682,UL 50, and UL 1010
- Material - Mounting Hardware:
- Cord Mounted
- Application:
- Metallic with Nylon Shroud
- Item Type:
- Male Plug
- Current / Amperage Rating:
- 200 A
- Amperage Rating:
- 200 A
- Cord Type:
- All Portable
- Package Quantity:
- 1
