Pipe Saddle Support, Galvanized, 2 1/2 In - 0500362009

Name: Pipe Saddle Support, Galvanized, 2 1/2 In - 0500362009
Brand: Anvil
SKU: 0500362009
Price: 215.04 USD
Availability: InStock

Anvil

SKU:

0500362009

UPC:

690291530173

Availability:

In Stock

(No reviews yet)

Pipe Saddle Support, Base Material Cast Iron, For Maximum Pipe Size 2 1/2 in, Load Capacity 1,800 lb, Maximum Height Adjustment 13 in, Minimum Height Adjustment 8 in, Overall Height 13 in, Overall Length 3 in, Pipe Support Type Saddle, Saddle Width 3 in, Support Material Cast Iron, Support Material Finish Galvanized

Country of Origin:: United States
Item:: Pipe Saddle Support
Material:: Cast Iron
Width:: 3 in
Vertical Adjustment Minimum:: 8 in
Type:: Adjustable
Max. Load:: 1,800 lb
Standards and Approvals:: A-A-1192A (Type 38), ANSI/MSS SP-69 &SP-58 (Type 38), WW-H-171E (Type 39)
Nominal Stanchion Pipe Size:: 2 1/2 in
Pipe Size:: 2 1/2 in
Vertical Adjustment Maximum:: 13 in
Finish:: Galvanized
Base Material:: Cast Iron
For Use On:: Pipe
Minimum Height Adjustment:: 8 in
Pipe Support Type:: Saddle
Support Material:: Cast Iron
Support Material Finish:: Galvanized
Height Adjustability:: Adjustable Height
For Maximum Pipe Size:: 2 1/2 in
Series:: Figure 264
Overall Length:: 3 in
Load Capacity:: 1,800 lb
Standards:: ANSI/MSS SP-69, Federal Specification A-A-1192A,Type 38, MSS SP-58,Type 38, WW-H-171-E,Type 39
Saddle Width:: 3 in
Maximum Height Adjustment:: 13 in
Overall Height:: 13 in
Package Quantity:: 1
