Pin & Slve Plug, 100A, 4P, 4W, 600VAC/250VDC - VP10477

Pin & Slve Plug, 100A, 4P, 4W, 600VAC/250VDC - VP10477

Hubbell
SKU:
VP10477
|
UPC:
783936834757
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Pin and Sleeve Plug, Current Rating 100 A, Hazardous Location Specification Class I, Div 1 and 2, Group A, B, C, D, Horsepower Rating Not Applicable, Housing Color Gray, IP Rating Not Rated, Number of Poles 4, Number of Wires 4, Phase Three, Voltage Rating 250V DC, 600V AC, Wire Connection Type Screw Terminals, Cap Type Not Applicable, Connection Orientation Straight, Face Diameter 2.75 in, Grounding Grounded, Grounding Style Style 1, Housing Material Copper-Free Aluminum
Additional Information
Country of Origin:
United States
Amps - Plugs and Receptacles:
100 A
Number of Poles:
4
Number of Wires:
4
Switch Rated:
No
Grounding Style:
Style 1
Item:
Pin and Sleeve Plug
Voltage:
600V AC/250V DC
Amps:
100 A
Standards:
CSA Certified LR111846, UL E10757
NEMA Rating:
4x
Material:
Copper Free Aluminum with Electro Statically Applied Epoxy, Powder Finish
Features:
Box Terminals with Gripper Ribs Securely Clamp Conductors, Octagonal Body Style, Suitable for Type P Marine Cable
Phase:
Three
Reverse Service:
No
Wire Connection Type:
Screw Terminals
Housing Color:
Gray
Face Diameter:
2.75 in
Overall Length:
10.875 in
Horsepower Rating:
Not Applicable
Minimum Wire Size:
4 AWG
Grounding:
Grounded
For Environment:
Cold, Corrosive, Hazardous Location, Marine, Wet
Outside Diameter:
4.25 in
Housing Material:
Metallic
For Location:
Indoor, Outdoor
Housing Material Finish:
Baked Powder Epoxy/Polyester Coated
Market:
Industrial
Voltage Rating:
250V DC, 600V AC
Cap Type:
Not Applicable
Connection Orientation:
Straight
NEMA Enclosure Rating:
4X
Shrouded:
Yes
Current Rating:
100 A
Power Indicating Light:
No
Hazardous Location Specification:
Class I, Div 1 and 2, Group A, B, C, D
IP Rating:
Not Rated
Maximum Wire Size:
2 AWG
Finish:
Baked Powder Epoxy/Polyester Finish
Hz:
50-400 Hz
Type:
Pin & Sleeve
Application:
Suitable for indoor or outdoor use. Applications include the wet, cold, hosedown, hazardous or corrosive areas in such industrial applications as
Series:
VersaMate
Width:
4.25 in
Finish Type:
Baked Powder Epoxy/Polyester Finish
Amperage Rating:
100 A
Dimensions:
10.87 in x 4.25 in x 4.25 in
Height:
4.25 in
Grommet Range:
0.88-1.68
Style:
Style I
Length:
10.87 in
Frequency Rating:
50-400 Hz
Package Quantity:
1
