Pin and Sleeve Plug, 4P, 5W, 60A, 600VAC - HBL560PS1W

Pin and Sleeve Plug, 4P, 5W, 60A, 600VAC - HBL560PS1W

Hubbell
SKU:
HBL560PS1W
|
UPC:
783585010663
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Type 4X Pin and Sleeve Plug, Current Rating 60 A, Housing Color Black, Gray, IP Rating Not Rated, Number of Poles 4, Number of Wires 5, Phase Three, Voltage Rating 250V DC, 600V AC, Wire Connection Type Screw Terminals, Cap Type No Cap or Cover, Connection Orientation Straight, For Maximum Cable Diameter 1.45 in, For Minimum Cable Diameter 0.5 in, Grounding Grounded, Grounding Style Style 1, Housing Material Polybutylene Terephthalate, Maximum Wire Size 4 AWG, Minimum Wire Size 6 AWG
Additional Information
Country of Origin:
United States
Item - Plugs and Receptacles:
Watertight Pin and Sleeve Plug
Body Material - Pin and Sleeve:
Valox 357 Housing and Aluminum Shroud
Amps - Plugs and Receptacles:
60
Voltage - Plugs and Receptacles:
600V AC/250V DC
Color - Plugs and Receptacles:
Gray
Number of Poles:
4
Number of Wires:
5
Phase - Electrical:
3
Switch Rated:
No
Grounding Style:
Style 1
Amps:
60
Phase:
Three
Features:
All-Brass Sleeve Contacts Provide Reliable Electrical Contact, Catalog Number and Rating Visible While in Use, Locking Ring Provides UL Type 4X Watertight, Dust-Tight Seal
Body Material:
Valox 357 Housing and Aluminum Shroud
Standards:
CSA Certified C22.2 No. 159, CSA Certified Type 4X, UL 1010, UL 1682, UL 50, UL Listed
Item:
Type 4X Pin and Sleeve Plug
Voltage:
600VAC/250VDC
Color:
Gray
Material:
Composite
Overall Length:
9.6 in
Outside Diameter:
3.7 in
Application:
Metallic with Nylon Shroud
NEMA Enclosure Rating:
4X
UL 94 Flammability Rating:
V-0
Housing Color:
Black, Gray
Housing Material:
Non-Metallic
Minimum Operating Temperature:
-40 Degrees C
Shrouded:
Yes
Current Rating:
60 A
Wire Connection Type:
Screw Terminals
Maximum Wire Size:
4 AWG
Power Indicating Light:
No
IP Rating:
Not Rated
Voltage Rating:
250V DC, 600V AC
Compatible with Series:
Insulgrip
Connection Orientation:
Straight
Cap Type:
No Cap or Cover
For Minimum Cable Diameter:
0.5 in
Reverse Service:
No
Grounding:
Grounded
Maximum Operating Temperature:
75 Degrees C
Minimum Wire Size:
6 AWG
For Maximum Cable Diameter:
1.45 in
Resistance Properties:
Impact Resistant, Moisture Resistant, Watertight
Type:
Watertight Plug
Max. Voltage:
600V
Mounting Box:
Stainless Steel (300 Series)
Hub Style:
Standard
Current / Amperage Rating:
60 A
OEM Brand Name:
Hubbell Wiring Device-Kellems
Voltage Rating Description:
600V AC/250V DC
Connectivity:
Pressure Terminal Screws
Item Type:
Male Plug
Nema Rating:
Non-NEMA
Amperage Rating:
60 A
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - Withstands 3,000V AC Electrical - Max. Working Voltage - 600V AC RMS Environmental - Flammability (Enclosure) - UL 94V-0 an
Environmental Conditions:
Watertight
Style:
Standard Service,Style 1 Grounding
Display Size:
Standard Sized
Cord Type:
All Portable
Industry Standard(s):
CSA Certified to CSA Spec. C22.2 No. 159 UL Listed and CSA Certified Type 4X UL Standard 1682,UL 50, and UL 1010
Material - Mounting Hardware:
Cord Mounted
Wire Size:
#6 AWG to #4 AWG
Series:
UL 1686 Class 1 Insulgrip®
Package Quantity:
1
