Pilot Light, Incan, Red, 380-480V - 9001KP5R31

Pilot Light, Incan, Red, 380-480V - 9001KP5R31

Schneider Electric
SKU:
9001KP5R31
|
UPC:
785901033127
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Pilot Light, Voltage 480V AC, Color Red, Lamp Type Incandescent, Shape Round, Terminal Connection Screw Clamp, Lens Material Polycarbonate, 30 mm, Lamp Module Type Transformer, Basic Material Metal, Lens Type Fresnel, Lamp Voltage 6V AC/DC, Replacement Lamps 4VCW2, Body Material Zinc Die Cast, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP66, Standards CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE
Additional Information
Country of Origin:
Mexico
Item:
Pilot Light
Voltage:
480V AC
Color:
Red
Action:
Normal
Lamp Type:
Incandescent
Shape:
Round
Terminal Connection:
Screw Clamp
Lens Material:
Polycarbonate
Bezel:
Metal
Lens Type:
Fresnel
Size:
30 mm
Lamp Module Type:
Transformer
Basic Material:
Metal
Lamp Voltage:
6V AC/DC
Body Material:
Zinc Die Cast
IP Rating:
IP66
Replacement Lamps:
4VCW2
NEMA Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Standards:
CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE
Hz:
50/60 Hz
Legend:
Not Applicable
Includes Push-To-Test:
No Push-To-Test Included
Hazardous Location Specification:
Not Applicable
Lamp Color:
Red
Lens Color:
Red
Overall Width:
2.13 in
Panel Cutout Diameter:
30 mm
Lamp Voltage - Maximum:
6 V AC/DC
Body Finish:
Chrome Plated
Includes Lens:
Lens Included
Includes Lamp Module:
Lamp Module Included
Voltage Rating - Maximum:
480 V AC
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Manufacturer Warranty Length:
18 mo
Series:
9001K
Overall Height:
3.02 in
Overall Depth:
1.62 in
ATEX Explosive Environment Rating:
Not Applicable
Package Quantity:
1
