Pilot Light Complete, Red, Incandescent - 9001KP1R9

Pilot Light Complete, Red, Incandescent - 9001KP1R9

Schneider Electric
SKU:
9001KP1R9
|
UPC:
785901005681
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Pilot Light, Voltage 120V AC, Color Red, Lamp Type Incandescent, Shape Round, Terminal Connection Screw Clamp, Lens Material Polycarbonate, 30 mm, Lamp Module Type Transformer, Basic Material Metal, Lens Type Domed, Lamp Voltage 6V AC/DC, Replacement Lamps 4VCW2, Body Material Zinc Die Cast, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP66, Standards REACH, RoHS, UL 508, WEEE
Additional Information
Country of Origin:
Mexico
Item:
Pilot Light
Voltage:
120V AC
Color:
Red
Lamp Type:
Incandescent
Shape:
Round
Terminal Connection:
Screw Clamp
Lens Material:
Polycarbonate
Bezel:
Metal
Size:
30 mm
Lens Type:
Domed
Lamp Module Type:
Transformer
Basic Material:
Metal
Body Material:
Zinc Die Cast
IP Rating:
IP66
NEMA Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Replacement Lamps:
4VCW2
Standards:
REACH, RoHS, UL 508, WEEE
Lamp Voltage:
6V AC/DC
Hz:
50/60 Hz
Legend:
Not Applicable
Includes Push-To-Test:
No Push-To-Test Included
Lamp Voltage - Maximum:
120 V AC
Resistance Properties:
Dust Resistant, Impact Resistant, Vibration Resistant, Waterproof
Overall Depth:
1.65 in
Hazardous Location Specification:
Not Applicable
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Body Finish:
Chrome Plated
Overall Width:
2.13 in
Voltage Rating - Maximum:
120 V AC
Series:
9001K
Includes Lamp Module:
Lamp Module Included
Manufacturer Warranty Length:
18 mo
Includes Lens:
Lens Included
Overall Height:
2.76 in
Lamp Color:
Red
Panel Cutout Diameter:
30 mm
Lens Color:
Red
ATEX Explosive Environment Rating:
Not Applicable
Package Quantity:
1
