Pilot Light Complete, Green, LED - XB4BVB3

Pilot Light Complete, Green, LED - XB4BVB3

Schneider Electric
SKU:
XB4BVB3
|
UPC:
785901381280
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Pilot Light, Voltage 24V AC, Color Green, Lamp Type LED, Shape Round, Terminal Connection Screw Clamp, Lens Material Plastic, 22 mm, Lamp Module Type Full Voltage, Basic Material Metal, Lens Type Smooth, Body Material Metal, NEMA Rating 13, 4, 4X, IP Rating IP66, IP67, IP69, IP69K, Includes Light Module, Standards CSA, REACH, RoHS, UL Listed, WEEE
Additional Information
Country of Origin:
France
Item:
Pilot Light
Voltage:
24V AC
Color:
Green
Lamp Type:
LED
Shape:
Round
Terminal Connection:
Screw Clamp
Contact Form:
(X1-X2)PL
Bezel:
Chromium Plated Metal
Lens Material:
Plastic
Size:
22 mm
Lens Type:
Smooth
Lamp Module Type:
Full Voltage
Basic Material:
Metal
IP Rating:
IP66, IP67, IP69, IP69K
Standards:
CSA, REACH, RoHS, UL Listed, WEEE
NEMA Rating:
13, 4, 4X
Includes:
Light Module
Body Material:
Metal
Width:
30 mm
Average Life:
100000 hr
Height:
47 mm
Length:
54 mm
Type:
Steady Signal
IK Degree Of Protection:
IK06 IEC 50102
Depth:
2.13 in (54 mm)
Light Source:
Universal LED
Rated Insulation Voltage:
250 V 3)IEC 60947-1
Service Life:
100000 h at rated voltage and 25°C
Resistance To High Pressure Washer:
1015.26 psi (7000000 Pa) 131°F (55°C) 0.1 m
Bulb Base:
Integral LED
Resistance To Electrostatic Discharge:
6 kV on contact (on metal parts) IEC 61000-4-2; 8 kV in free air (in insulating parts) IEC 61000-4-2
Product Or Component Type:
Pilot light
Ambient Air Temperature For Storage:
-40 to 158°F (-40 to 70°C)
Surge Withstand:
1 kV IEC 61000-4-5
IP Degree Of Protection:
IP66 IEC 60529; IP67; IP69; IP69K
Product Certifications:
CSA; UL Listed
Rated Impulse Withstand Voltage:
4 kV IEC 60947-1
Signalling Type:
Steady
Electrical Shock Protection Class:
Class I IEC 60536
Fixing Collar Material:
Zamak
Protective Treatment:
TH
Electromagnetic Emission:
Class B IEC 55011
Resistance To Electromagnetic Fields:
9.14 V/m (10 V/m) IEC 61000-4-3
Device Presentation:
Complete product
Mounting Diameter:
0.87 in (22 mm)
Ambient Air Temperature For Operation:
-40 to 158°F (-40 to 70°C)
NEMA Degree Of Protection:
NEMA 13; NEMA 4X
Rated Supply Voltage:
24 V AC/DC 50/60 Hz
Resistance To Fast Transients:
2 kV IEC 61000-4-4
Connections - Terminals:
Screw clamp terminals, Less than or Equal to 2 x 1.5 mm² with cable end IEC 60947-1; Screw clamp terminals, 1 x 0.22 to 2 x 2.5 mm² without cable end IEC 60947-1
Vibration Resistance:
5 gn 12 to 500 Hz)IEC 60068-2-6
Supply Voltage Limits:
19.2 to 30 V DC; 21.6 to 26.4 V AC
Head Type:
Standard
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27; 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Current Consumption:
18 mA
Body Finish:
Chrome Plated
Series:
XB4
NEMA Enclosure Rating:
13, 4X
Includes Lens:
Lens Included
Includes Push-To-Test:
No Push-To-Test Included
Lens Color:
Green
Resistance Properties:
Dust Resistant, Impact Resistant, Vibration Resistant, Waterproof
Voltage Rating - Maximum:
24 V AC/DC
Panel Cutout Diameter:
22 mm
Lamp Color:
Green
Manufacturer Warranty Length:
18 mo
Overall Height:
1.85 in
Includes Lamp Module:
Lamp Module Included
Overall Depth:
2.13 in
Overall Width:
1.18 in
Package Quantity:
1
