Photoelectric Sensor, Cylindrical, Diffuse - 13101A6517

Name: Photoelectric Sensor, Cylindrical, Diffuse - 13101A6517
Brand: Eaton
SKU: 13101A6517
Price: 355.34 USD
Availability: InStock

Eaton

SKU:

13101A6517

UPC:

782113928203

Availability:

In Stock

(No reviews yet)

Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Diffuse, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 10 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 2m Cable, Circuit Type - Cylindrical Photoelectric Sensor NPN/PNP, Max. Sensing Distance - Cylindrical Photoelectric Sensor 100 mm

Country of Origin:: Mexico
Item:: Photoelectric Sensor
Width:: 3.46";Depth=0.47""
Min. Object Size:: Adjustable By Changing Gain
Diameter - Cylindrical Photoelectric Sensor:: 18 mm
IP Rating:: IP69K
Max. Sensing Distance - Cylindrical Photoelectric Sensor:: 100 mm
Response Time (ms):: 1
Circuit Type - Cylindrical Photoelectric Sensor:: NPN/PNP
Length - Cylindrical Photoelectric Sensor:: 66 mm
Standards:: cUL, UL Listed
Length:: 2.60";Max. Sensing Distance=100mm"
Electrical Connection:: Bare Wire
Body Material:: Polyurethane
Light Source:: Red LED
Power Requirement:: 10 to 30VDC
Operation Mode:: Selectable Light On/Dark On
Circuit Type:: NPN/PNP
Operating Mode - Photoelectric Sensor:: Selectable Light On/Dark On
Electrical Connection - Cylindrical Photoelectric Sensor:: 2m Cable
Power Requirement - Cylindrical Photoelectric Sensor:: 10 to 30V DC
NEMA Rating:: 1, 12, 13, 2, 3, 4, 4X, 6
Operating Frequency:: 500 Hz
Shape:: Cylindrical
Diameter:: 18mm
Sensing Method - Cylindrical Photoelectric Sensor:: Diffuse
Features:: Auto Reset Short Circuit
Response Time:: 1 msec
Max. Load Current:: 250 mA
Operating Temp. Range:: -40 Degrees to 70 Degrees C
Sensing Method:: Diffuse
Overall Height:: 18 mm
Cable Length:: 2 m
Environmental rating:: NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Cord length:: 79.2 ft
Enclosure Material:: Polyurethane foam (RIM)
LED indicator:: Output ON
Certifications:: UL Recognized
Cable type:: Polyvinyl Chloride (PVC)
Sensor type:: Back ground suppression
Maximum DC current:: 100 mA PNP, 250 mA NPN
Contact Rating:: 100 mA PNP, 250 mA NPN at 10-30 Vdc
Product Width:: .47 in
Type:: Perfect Prox Photoelectric Sensor
Operating temperature - min:: -40Â°F
Input voltage:: 10-30 Vdc
Operating temperature - max:: 158Â°F
Product Length/Depth:: 2.06 in
Product Height:: .71 in
Contact configuration:: NPN and PNP open collector
Protection:: Auto reset short circuit
Product Name:: Eaton Comet 18mm tubular photoelectric sensor
NEMA Enclosure Rating:: 1, 12, 13, 3, 4, 4X, 6
Includes Indicator Lights:: Indicator Lights Included
Orientation:: Straight
Switching Frequency:: 500 Hz
Load Current - Maximum:: 250 mA
Output Circuit Relay Style:: Not Applicable
Electrical Installation Type:: Prewired Cable
Style:: Cylindrical
Overall Width:: 12 mm
Sensing Distance - Minimum:: 13 mm
DC Voltage Rating:: 10-30V DC
Sensor Diameter:: 18 mm
Series:: Comet
Operating Temperature - Maximum:: 158 Degrees F
Product Type:: Photoelectric Sensor
Overall Diameter:: 18 mm
Operating Temperature - Minimum:: -40 Degrees F
Output Circuit Type:: NPN and PNP
Operating Mode:: Selectable Light On/Dark On
Emitted Sensor Light:: Infrared
Sensing Distance - Maximum:: 100 mm
Overall Depth:: 52 mm
Package Quantity:: 1
