Photoelectric Sensor, Cylinder, Thru-Beam - XU2M18MA230

Photoelectric Sensor, Cylinder, Thru-Beam - XU2M18MA230

Telemecanique Sensors
SKU:
XU2M18MA230
|
UPC:
785901348979
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Photoelectric Sensor Set, Sensing Method - Cylindrical Photoelectric Sensor Through Beam Set, Operating Mode - Photoelectric Sensor Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 24 to 240V AC/DC, Electrical Connection - Cylindrical Photoelectric Sensor 2m Cable, Circuit Type - Cylindrical Photoelectric Sensor Solid State Relay, SPST, Max. Sensing Distance - Cylindrical Photoelectric Sensor 20 m
Additional Information
Country of Origin:
France
Item:
Photoelectric Sensor Set
Material:
metal
Light Source:
Red and Yellow LED
Electrical Connection - Cylindrical Photoelectric Sensor:
2m Cable
Circuit Type - Cylindrical Photoelectric Sensor:
Solid State Relay, SPST
Operating Temp. Range:
-25 Degrees to 55 Degrees C
Diameter - Cylindrical Photoelectric Sensor:
18 mm
Features:
PMMA Lens
Operating Mode - Photoelectric Sensor:
Dark On
Length:
82 mm
Length - Cylindrical Photoelectric Sensor:
18 mm
Response Time:
20.0 msec
Max. Sensing Distance - Cylindrical Photoelectric Sensor:
20 m
Standards:
CE, CSA, IEC 60529, RoHS, UL Listed
Sensing Method:
Through-Beam
IP Rating:
IP67
Body Material:
Brass
NEMA Rating:
Not Rated
Electrical Connection:
Bare Wire
Max. Load Current:
200 mA
Power Requirement - Cylindrical Photoelectric Sensor:
24 to 240V AC/DC
Diameter:
18 mm
Operating Frequency:
25 Hz
Sensing Method - Cylindrical Photoelectric Sensor:
Through Beam Set
Cable Length:
2 m
Overall Height:
95 mm
Line Of Sight Type:
axial
Ambient Air Temperature For Storage:
-40-70°C
Switching Capacity In Ma:
10...200 mA to be used with 0.4 A quick-blow fuse in series with the load)
Product Certifications:
CE || CSA || UL
Maximum Delay Recovery:
20 ms
Vibration Resistance:
7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
Maximum Delay First Up:
300 ms
Enclosure Material:
Nickel Plated Brass
Maximum Residual Current:
1.5 mA open state
Wiring Technique:
2-wire
Ambient Air Temperature For Operation:
-25-55°C
Lens Material:
PMMA
Sensor Name:
XU2
Wire Insulation Material:
PvR
Discrete Output Function:
1 NO
Status Led:
1 LED yellow)output state || 1 LED red)instability
Series Name:
general purpose single mode
Detection System:
thru beam
Kit Composition:
transmitter + receiver XU2M18MC230T + XU2M18MA230R
Electronic Sensor Type:
photo-electric sensor
Maximum Sensing Distance:
20 m
Maximum Delay Response:
20 ms
Ip Degree Of Protection:
IP67 double insulation IEC 60529
Sensor Design:
cylindrical M18
Supply Voltage Limits:
20-264 V AC/DC
Switching Frequency:
25 Hz
Output Type:
solid state
[Us] Rated Supply Voltage:
24...240 V AC/DC
Add On Output:
without
Maximum Voltage Drop:
<6 V closed state)
[Sn] Nominal Sensing Distance:
15-15 m thru beam
Type Of Output Signal:
discrete
Shock Resistance:
30 gn 11 ms) IEC 60068-2-27
Emission:
infrared thru beam
Supply Circuit Type:
AC/DC
Setting-Up:
sensitivity adjustment
Electrical Installation Type:
Prewired Cable
Operating Temperature - Minimum:
-13 Degrees F
Load Current - Maximum:
200 mA
Emitted Sensor Light:
Infrared
AC Voltage Rating:
24-240V AC
Overall Diameter:
18 mm
Orientation:
Straight
Sensor Diameter:
18 mm
NEMA Enclosure Rating:
No Enclosure
Product Type:
Photoelectric Sensor Transmitter and Receiver Set
DC Voltage Rating:
24-240V DC
Output Circuit Type:
Relay
Output Circuit Contact Form:
1NO
Operating Mode:
Dark On
Sensing Distance - Maximum:
15 m
Operating Temperature - Maximum:
131 Degrees F
Includes Indicator Lights:
Indicator Lights Included
Style:
Cylindrical
Series:
XU
Package Quantity:
1
