Photoelectric Sensor, Cylinder, Reflective - E65-SMPR3-HDD

Photoelectric Sensor, Cylinder, Reflective - E65-SMPR3-HDD

Eaton
SKU:
E65-SMPR3-HDD
|
UPC:
782114786536
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Retroreflective, Operating Mode - Photoelectric Sensor Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 10 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 4-Pin Micro Connector, Circuit Type - Cylindrical Photoelectric Sensor NPN/PNP, Max. Sensing Distance - Cylindrical Photoelectric Sensor 3 m, Length - Cylindrical Photoelectric Sensor 55 mm
Additional Information
Country of Origin:
Mexico
Item:
Photoelectric Sensor
Width:
1.29";Depth=1.63""
Operating Temp. Range:
-25 Degrees to 55 Degrees C
Response Time (ms):
1
Body Material:
Resin
Diameter:
18mm
Shape:
Cylindrical
Features:
Auto Reset Short Circuit
NEMA Rating:
1, 12, 13, 3, 4, 6, 6P
Sensing Method:
Retroreflective
Circuit Type - Cylindrical Photoelectric Sensor:
NPN/PNP
Power Requirement - Cylindrical Photoelectric Sensor:
10 to 30V DC
Diameter - Cylindrical Photoelectric Sensor:
18 mm
Min. Object Size:
Adjustable By Changing Gain
Max. Load Current:
100 mA
Electrical Connection - Cylindrical Photoelectric Sensor:
4-Pin Micro Connector
Length:
2.17";IP Rating=IP68, IP69K"
Operation Mode:
Dark On
Length - Cylindrical Photoelectric Sensor:
55 mm
Light Source:
Red LED
Sensing Method - Cylindrical Photoelectric Sensor:
Retroreflective
Power Requirement:
10 to 30VDC
Operating Mode - Photoelectric Sensor:
Dark On
Max. Sensing Distance - Cylindrical Photoelectric Sensor:
3 m
Electrical Connection:
M12
Standards:
CE, cUL, UL Listed
Operating Frequency:
500 Hz
Response Time:
1 msec
Overall Height:
37 mm
Environmental rating:
NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13, IP68, IP69K 2
Protection:
Auto reset short circuit
Product Height:
1.47 in
Operating temperature - min:
-13°F
Compliances:
CE Marked
Operating mode:
Light
Series:
E65 SM
Connection:
M12
LED indicator:
TargetLock
Enclosure Material:
Cable jacket
Product Width:
2.17 in
Maximum DC current:
100 mA
Product Length/Depth:
1.29 in
Sensor type:
Polarized retroreflective
Certifications:
cUL Listed
Contact Rating:
100 mA at 10-30 Vdc
Input voltage:
10-30 Vdc
Operating temperature - max:
131°F
Contact configuration:
NPN and PNP open collector
Product Name:
Eaton E65 SM compact photoelectric sensor
Output Circuit Type:
NPN and PNP
Overall Depth:
33 mm
Overall Diameter:
18 mm
Switching Frequency:
500 Hz
Operating Mode:
Dark On
Includes Indicator Lights:
Indicator Lights Included
Style:
Cylindrical
Operating Temperature - Minimum:
-13 Degrees F
Sensor Diameter:
18 mm
Operating Temperature - Maximum:
131 Degrees F
NEMA Enclosure Rating:
1, 12, 13, 3, 4, 4X, 6, 6P
Emitted Sensor Light:
Infrared
Overall Width:
55 mm
Load Current - Maximum:
100 mA
Orientation:
Right Angle
Electrical Installation Type:
Direct Connector
Output Circuit Relay Style:
Not Applicable
Product Type:
Photoelectric Sensor
Sensing Distance - Maximum:
3 m
Sensing Distance - Minimum:
30 mm
DC Voltage Rating:
10-30V DC
Package Quantity:
1
