Photoelectric Sensor, Cylinder, Reflective - 14101RQD03

Photoelectric Sensor, Cylinder, Reflective - 14101RQD03

Eaton
SKU:
14101RQD03
|
UPC:
782113846675
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Retroreflective, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 20 to 264V AC/15 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 4-Pin Micro Connector, Circuit Type - Cylindrical Photoelectric Sensor NPN, Max. Sensing Distance - Cylindrical Photoelectric Sensor 3 m
Additional Information
Country of Origin:
Mexico
Item:
Photoelectric Sensor
Power Requirement - Cylindrical Photoelectric Sensor:
20 to 264V AC/15 to 30V DC
Standards:
cUL, UL Listed
Diameter - Cylindrical Photoelectric Sensor:
18 mm
Body Material:
Polyurethane
Sensing Method:
Polarized Retroreflective
Electrical Connection:
Dual Key Micro Connector
NEMA Rating:
1, 12, 13, 2, 3, 4, 4X, 6
Min. Object Size:
Adjustable By Changing Gain
Max. Sensing Distance - Cylindrical Photoelectric Sensor:
3 m
Max. Load Current:
300 mA
Light Source:
Red LED
Features:
Latching Short Circuit
Operating Frequency:
500 Hz
Operating Mode - Photoelectric Sensor:
Selectable Light On/Dark On
Response Time:
10 msec
IP Rating:
IP69K
Response Time (ms):
10
Circuit Type - Cylindrical Photoelectric Sensor:
NPN
Operating Temp. Range:
-40 Degrees to 70 Degrees C
Sensing Method - Cylindrical Photoelectric Sensor:
Retroreflective
Electrical Connection - Cylindrical Photoelectric Sensor:
4-Pin Micro Connector
Length - Cylindrical Photoelectric Sensor:
76 mm
Overall Height:
18 mm
Environmental rating:
NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13, IP69K
Certifications:
UL Recognized
Sensor type:
Polarized retroreflective
Maximum AC current:
300 mA
Operating temperature - min:
-40°F
Input voltage:
20-264 Vac at 50/60 Hz, 15-30 Vdc (NPN)
Contact Rating:
300 mA AC/DC at 20-264 Vac/15-30 Vdc
Operating temperature - max:
158°F
Contact configuration:
AC
LED indicator:
Output ON
Product Width:
.47 in
Maximum DC current:
300 mA
Protection:
Latching short circuit
Product Height:
.71 in
Enclosure Material:
Polyurethane foam (RIM)
Product Length/Depth:
3 in
Connection:
Dual key micro
Product Name:
Eaton Comet 18mm tubular photoelectric sensor
AC Voltage Rating:
20-264V AC
Overall Diameter:
18 mm
Orientation:
Right Angle
Overall Depth:
76 mm
Sensing Distance - Minimum:
30 mm
Emitted Sensor Light:
Infrared
Style:
Cylindrical
Electrical Installation Type:
Direct Connector
Operating Temperature - Minimum:
-40 Degrees F
Operating Mode:
Selectable Light On/Dark On
Output Circuit Type:
NPN
Series:
Comet
DC Voltage Rating:
15-30V DC
Switching Frequency:
500 Hz
Sensor Diameter:
18 mm
NEMA Enclosure Rating:
1, 12, 13, 3, 4, 4X, 6
Load Current - Maximum:
300 mA
Operating Temperature - Maximum:
158 Degrees F
Includes Indicator Lights:
Indicator Lights Included
Output Circuit Relay Style:
Not Applicable
Sensing Distance - Maximum:
3 m
Product Type:
Photoelectric Sensor
Overall Width:
12 mm
Package Quantity:
1
