Ovrload Rely, 5.50 to 8A, 3P, Class 10,690V - 3RU21161HB0

Ovrload Rely, 5.50 to 8A, 3P, Class 10,690V - 3RU21161HB0

Siemens
SKU:
3RU21161HB0
|
UPC:
662643920444
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Overload Relay, Auxiliary Contact Form 1NO/1NC, Maximum Overload Relay Current Setting 8 A, Minimum Overload Relay Current Setting 5.5 A, Trip Class 10, Maximum Voltage Rating 690V AC, NEMA Size Not Applicable, Number of Poles 3, Number of Required Thermals 3, Reset Type Auto, Manual, Includes Thermal Units Yes, Mounting Style Direct To Contactor, Terminal Connection Type Screw Terminals, Compatible with Series SIRIUS, Frame Size S00, Relay Style IEC, Overload Protection Type Thermal
Additional Information
Country of Origin:
Germany
Item:
Overload Relay
Item - Relay:
IEC Style Overload Relay
Use With - Contactors and Starters:
Mfr. Series 3RT201 Contactors
Current Range:
5.50 to 8.00A
Overload Relay Current Range:
5.5 to 8.0A
NEMA Size:
Not Applicable
Trip Class - Overload:
10
Width:
1.77";Number of Poles=3"
Frame / Series / Class / Code:
S00
Height:
3.00";Sensing Method=Thermal"
Reset Type - Relay:
Auto, Manual
Depth:
2.75";For Use With=3RT201 Contactors"
Separate Mounting:
Yes, Additional Items Needed
Body Height - Relay:
3 in
Body Depth - Relay:
2.75 in
Standards:
REACH Art 33 Duty to Inform According to the Current List of Candidates Lead CAS-No. 7439-92-1 Greater Than 0, 1 % (w/w), RoHS 07/01/2006, WEEE (2012/19/EU) Take-Back Obligation
Features:
Manual and Auto Reset
Overall Height - Relay:
3 in
Trip Class:
10
Body Width - Relay:
1.77 in
Mounting:
Contactor mounting
Starter Type:
IEC
Type:
thermal overload relay
Full Load Current Range:
8 A / 8 A
Insulation:
IP20
Contact configuration:
1 / 0 / 1
Operating Temperature:
-40°C to 70°C
Environmental Conditions:
-55
Trip type:
CLASS 10
Contact Rating:
B600 / R300
Size:
0.045 m / 0.076 m / 0.07 m
Minimum Operating Temperature:
-40 Degrees F
Body Width:
1.77 in
Overall Height:
3 in
Body Height:
2.99 in
Body Depth:
2.76 in
Terminal Connection Type:
Screw Terminals
Overload Protection Type:
Thermal
Includes Thermal Units:
Yes
Auxiliary Contact Form:
1NO/1NC
Compatible with Series:
SIRIUS
Reset Type:
Auto, Manual
Frame Size:
S00
IP Rating:
IP20
Maximum Overload Relay Current Setting:
8 A
Includes Mounting Hardware:
Not Applicable
Maximum Operating Temperature:
158 Degrees F
Relay Style:
IEC
Number of Required Thermals:
3
Minimum Overload Relay Current Setting:
5.5 A
Mounting Style:
Direct To Contactor
Maximum Voltage Rating:
690V AC
Phase:
Three
Package Quantity:
1
