Nonreversing NEMA Magnetic Motor Starter, 1 NEMA Rating, 208V AC, 3 Poles, 1NO - 14LPU32BD

Nonreversing NEMA Magnetic Motor Starter, 1 NEMA Rating, 208V AC, 3 Poles, 1NO - 14LPU32BD

Siemens
SKU:
14LPU32BD
|
UPC:
783087666641
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
NEMA Magnetic Motor Starter, Includes Auxiliary Contacts Yes, Maximum Overload Relay Current Setting 250 A, Overload Protection Type Electronic, Minimum Overload Relay Current Setting 55 A, Trip Class 20, Series FVNR, Number of Poles 3, Number of Auxillary Contacts 4, Phase Three, Mounting Style Surface, Auxiliary Contact Form 2NO/2NC, Starter Style NEMA, Reversing Capability Non-Reversing, Maximum Voltage Rating 600V AC, Coil Voltage 200-208V AC, Horsepower @ Three Phase - 600V AC 200 hp
Additional Information
Country of Origin:
United States
Item:
NEMA Magnetic Motor Starter
Overload Relay Amp Setting:
55 to 250A
Coil Volts:
208V AC
Enclosure NEMA Rating:
1
Auxiliary Contact Form:
2NO/2NC
HP @ 3 Phase - 240V:
100 hp
Starter Type:
NEMA Style
Action:
Nonreversing
Amps AC:
270
NEMA Size:
5
Number of Poles:
3
HP @ 3 Phase - 480V:
200 hp
HP @ 3 Phase - 208V:
75 hp
Width:
20 in
Standards:
NEMA ICS 2, UL 508
Height:
40 in
Hz:
60
HP @ 3 Phase - 575V:
200 hp
Depth:
11 in
Thermal Unit Code:
Not Applicable
Series:
FVNR
Maximum Operating Temperature:
104 Degrees F
Overall Depth:
11 in
Maximum Voltage Rating:
600V AC
Current AC:
270 A
Minimum Operating Temperature:
-4 Degrees F
Frequency:
50/60 Hz
Horsepower @ Three Phase - 240V AC:
100 hp
Mechanical Operating Durability:
10,000,000
Trip Class:
20
Number of Auxillary Contacts:
4
Phase:
Three
NEMA Enclosure Rating:
1
Auxiliary Contact Module Capacity:
8
Horsepower @ Three Phase - 480V AC:
200 hp
Horsepower @ Three Phase - 208V AC:
75 hp
Mounting Postion:
Vertical
Maximum Overload Relay Current Setting:
250 A
Reversing Capability:
Non-Reversing
Mounting Style:
Surface
Overall Width:
20 in
Coil Voltage:
200-208V AC
Horsepower @ Three Phase - 600V AC:
200 hp
Overload Protection Type:
Electronic
Starter Style:
NEMA
Overall Height:
40 in
Response Time:
10 to 24 msec (OFF-Delay Time), 19 to 29 msec (ON-Delay Time)
Includes Auxiliary Contacts:
Yes
Terminal Connection Type:
Screw Terminals
Minimum Overload Relay Current Setting:
55 A
Package Quantity:
1
