Nonreversing 1 NEMA Rating, 208 to 240V AC - A25CGE40B

Nonreversing 1 NEMA Rating, 208 to 240V AC - A25CGE40B

Eaton
SKU:
A25CGE40B
|
UPC:
782113757636
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Definite Purpose Magnetic Motor Starter, Series A25, Coil Voltage 208-240V AC, Terminal Connection Type Screw Terminals, Horsepower @ Three Phase - 600V AC 20 hp, Horsepower @ Three Phase - 480V AC 20 hp, Horsepower @ Three Phase - 240V AC 10 hp, Horsepower @ Single Phase - 240V AC 7 1/2 hp, Horsepower @ Single Phase - 120V AC 3 hp, Current AC 40 A, Number of Poles 3, NEMA Enclosure Rating 1, Reversing Capability Non-Reversing, Phase Three, Overload Protection Type Thermal
Additional Information
Country of Origin:
United States
Item:
Definite Purpose Magnetic Motor Starter
Type:
Non-reversing
Coil Volts:
208 to 240V AC
Enclosure NEMA Rating:
1
HP @ 3 Phase - 240V:
10 hp
HP @ 1 Phase - 240V:
7 1/2 hp
Action:
Nonreversing
HP @ 3 Phase - 575V:
20 hp
Amps AC:
40 A
Number of Poles:
3
HP @ 3 Phase - 480V:
20 hp
HP @ 1 Phase - 120V:
3 hp
Hz:
50/60
Height:
13.27 in
Width:
7.64 in
Standards:
CSA, UL Listed
Depth:
6.67 in
Model:
Starter
Product Name:
Eaton definite purpose starter
Terminals:
Box lugs (posidrive setscrew)
Control Characteristics:
Common control
Inductive Full Load:
40 A IFL
Enclosure:
NEMA type 1 enclosed
Coil:
208-240 Vac, 50/60 Hz
Product Width:
6 in
Phase:
Three
Product Length/Depth:
7.62 in
Amperage Rating:
40A
Product Height:
12.6 in
Certifications:
CSA Certified;UL Recognized
Current AC:
40 A
Horsepower @ Three Phase - 600V AC:
20 hp
Minimum Operating Temperature:
-13 Degrees F
Overall Width:
6 in
Horsepower @ Single Phase - 240V AC:
7 1/2 hp
Maximum Operating Temperature:
149 Degrees F
Series:
A25
Mounting Hole Distance - Height:
10.39 in
Horsepower @ Three Phase - 480V AC:
20 hp
Terminal Connection Type:
Screw Terminals
Overall Height:
12.6 in
Overload Protection Type:
Thermal
NEMA Enclosure Rating:
1
Coil Voltage:
208-240V AC
Overall Depth:
7.62 in
Horsepower @ Single Phase - 120V AC:
3 hp
Locked Rotor Load:
160 A @ 575V AC, 200 A @ 460V AC, 240 A @ 115V AC, 240 A @ 230V AC
Frequency:
50/60 Hz
Mounting Hole Distance - Width:
6 in
IP Rating:
IP20
Horsepower @ Three Phase - 240V AC:
10 hp
Reversing Capability:
Non-Reversing
Package Quantity:
1
