Non-Illuminated Push Button, 30 mm, 2NO/2NC, Universal - 9001KR1UH2

Non-Illuminated Push Button, 30 mm, 2NO/2NC, Universal - 9001KR1UH2

Schneider Electric
SKU:
9001KR1UH2
|
UPC:
785901148128
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Flush Push Button Operator, 30 mm, Momentary Action, Flush Button Type of Operator, Head Material Metal, Contact Form DPDT, Bezel Chrome Plated Die Cast Aluminum, Color Universal, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 1, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP20, IP65, Legend Not Applicable, Standards CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, UL A600, UL Q600, WEEE, Terminal Connection Screw Clamp
Additional Information
Country of Origin:
Mexico
Action:
Momentary
Size:
30 mm
Head Material:
Metal
NEMA Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Type of Operator:
Flush Button
Lamp Type:
Not Applicable
Contact Form:
DPDT
Color:
Universal
Legend:
Not Applicable
Bezel:
Chrome Plated Die Cast Aluminum
Number of Operators:
1
Contact Rating:
10A @ 600V AC
Item:
Flush Push Button Operator
Bezel Material:
Metal
Basic Material:
Metal
IP Rating:
IP20, IP65
Standards:
CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, UL A600, UL Q600, WEEE
NEMA Contact Rating Designation:
A600/Q600
Material:
metal
Terminal Connection:
Screw Clamp
Includes:
Black, Red, Green, Yellow, Blue, Orange and White Push Button Insert
Lamp Module Type:
Not Applicable
Series:
9001K
AC Contact Rating:
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
Product Type:
Push Button Operators
Legend Color:
Not Applicable
Push Button Style:
Flush
Panel Cutout Diameter:
30 mm
Manufacturer Warranty Length:
18 mo
Operator Material:
Metal
Number of Indicator Lights:
0
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Operator Voltage Rating - Maximum:
600 V AC
Maintained Action Release:
Not Applicable
Head Color:
Black, Blue, Green, Orange, Red, White, Yellow
Mushroom Head Diameter:
Not Applicable
Lamp Voltage - Maximum:
Not Applicable
Operating Temperature - Minimum:
-22 Degrees F
Legend Background Color:
Not Applicable
Hazardous Location Specification:
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Operating Temperature - Maximum:
140 Degrees F
Operator Illumination:
Non-Illuminated
Device Presentation:
complete product
Product Or Component Type:
push-button
Contacts Type And Composition:
2 C/O
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/6/12/13
Mounting Diameter:
30 mm
Contact Operation:
standard
[Ie] Rated Operational Current:
10 A, AC-15 || 10 A, DC-13
Light Block Supply:
without supply
Operator Additional Information:
metal guard
Product Certifications:
NEMA || CSA LR 25490 class 3211 03 || UL listed file E42259 CCN NKCR || CE
Light Source:
without
Operator Profile:
white projecting || orange projecting || black projecting || red projecting || green projecting || yellow projecting || blue projecting, flush
Cap/Operator Or Lens Colour:
7 colours choice
Device Short Name:
K
Package Quantity:
1
