Non-Illuminated Push Button, 30 mm, 1NO/1NC, Red - 52PP2A2A

Non-Illuminated Push Button, 30 mm, 1NO/1NC, Red - 52PP2A2A

Siemens
SKU:
52PP2A2A
|
UPC:
662643854398
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Mushroom Head Push Button, 30 mm, Maintained Action, 45mm Mushroom Head Type of Operator, Head Material Metal, Contact Form 1NO/1NC, Bezel Chrome Plated Zinc Die Cast, Color Red, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/P600, Number of Operators 1, NEMA Rating 1, 12, 13, 3, 3R, 4, 4X, IP Rating IP10, IP11, IP14, IP52, IP54, IP56, IP66, Legend Not Applicable, Standards CSA, REACH, UL Listed, Terminal Connection Pressure Plate
Additional Information
Country of Origin:
Mexico
Action:
Maintained
Size:
30 mm
Head Material:
Metal
NEMA Rating:
1, 12, 13, 3, 3R, 4, 4X
Type of Operator:
45mm Mushroom Head
Lamp Type:
Not Applicable
Color:
Red
Contact Form:
1NO/1NC
Legend:
Not Applicable
Bezel:
Chrome Plated Zinc Die Cast
Number of Operators:
1
Item:
Mushroom Head Push Button
Contact Rating:
10A @ 600V AC
Bezel Material:
Chrome
Terminal Connection:
Pressure Plate
Standards:
CSA, REACH, UL Listed
Basic Material:
Metal
NEMA Contact Rating Designation:
A600/P600
Material:
metal
Lamp Module Type:
Not Applicable
IP Rating:
IP10, IP11, IP14, IP52, IP54, IP56, IP66
Features:
Bifurcated Movable Contacts, Boots Not Required, NEMA A600/P600 Contacts, Octagonal Mounting Nuts, Positive Indexing Selectors, Positively Driven Contacts, Touchsafe Terminals
DC Contact Rating:
Not Rated
Series:
Class 52
AC Contact Rating:
10 A @ 600 V
Product Type:
Push Button Operators
Legend Background Color:
Not Applicable
NEMA Enclosure Rating:
1, 12, 13, 3, 3R, 4, 4X
Operator Material:
Metal
Panel Cutout Diameter:
30 mm
Head Color:
Red
Operator Illumination:
Non-Illuminated
Number of Indicator Lights:
0
Legend Color:
Not Applicable
Operator Voltage Rating - Maximum:
600 V AC
Push Button Style:
Mushroom Head
Manufacturer Warranty Length:
1 yr
Maintained Action Release:
Push/Pull
Operating Temperature - Minimum:
31 Degrees F
Overall Height:
4.56 in
Mechanical Operating Durability:
3.00 x 10^5
Overall Width:
2.12 in
Hazardous Location Specification:
Class I, Div 2, Group A, B, C, D
Lamp Voltage - Maximum:
Not Applicable
Mushroom Head Diameter:
43.94 mm
Resistance Properties:
Oil and Grease Resistant, Watertight
Operating Temperature - Maximum:
158 Degrees F
Package Quantity:
1
