Non-Illum Selector Swtch, Zamak/SS, Chrome - XB4BG03

Non-Illum Selector Swtch, Zamak/SS, Chrome - XB4BG03

Schneider Electric
SKU:
XB4BG03
|
UPC:
785901380634
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Selector Switch, 22 mm, 3 Position, Maintained/Maintained/Maintained Action, 2NO Contact Form, Type of Operator Keyed, Color Chrome, Any Position Key Removal, Operator Head Material Metal, Basic Material Metal, Bezel Material Chrome Plated Metal, Bezel Color Chrome, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation B600/Q600, NEMA Rating 1, 12, 13, 2, 3, 4, IP Rating IP66, IP67, IP69, IP69K, Cam No Cam Included, Switch Operation @ Position A XO, Switch Operation @ Position B OO
Additional Information
Country of Origin:
France
Item:
Selector Switch
Size:
22 mm
Basic Material:
Metal
Type of Operator:
Keyed
Contact Form:
2NO
Action:
Maintained/Maintained/Maintained
Operator Head Material:
Metal
Cam:
No Cam Included
Color:
Chrome
NEMA Rating:
1, 12, 13, 2, 3, 4
Bezel Material:
Chrome Plated Metal
Position:
3
Key Removal:
Any Position
Bezel Color:
Chrome
Switch Operation @ Position C:
OX
Switch Operation @ Position A:
XO
IP Rating:
IP66, IP67, IP69, IP69K
Contact Rating:
10A @ 600V AC
Includes:
Key
Switch Operation @ Position B:
OO
Switch Operation @ Position D:
No Fourth Position
Standards:
BV, CSA, DNV, GL, LROS, UL Listed
NEMA Contact Rating Designation:
B600/Q600
Lamp Module Type:
Not Applicable
Lamp Type:
Not Applicable
Width:
30 mm
Height:
47 mm
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
Series:
XB4
Depth:
86 mm
AC Contact Rating:
1.2 A @ 600 V, 3 A @ 240 V, 6 A @ 120 V
Fixing Collar Material:
zamak
Ip Degree Of Protection:
IP66 IEC 60529 || IP69 || IP69K || IP67
Tightening Torque:
0.8-1.2 N.m EN 60947-1
Electrical Reliability:
λ < 10exp(-6) 5 V 1 mA in clean environment EN/IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment EN/IEC 60947-5-4
Operator Position Information:
3 positions +/- 45°
Mounting Diameter:
22 mm
Torque Value:
0.14 N.m NO changing electrical state
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A600 EN/IEC 60947-5-1 || 6 A 120 V, AC-15, A600 EN/IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 EN/IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 EN/IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 EN/IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 EN
Positive Opening:
without
Contacts Material:
silver alloy (Ag/Ni)
Resistance To High Pressure Washer:
7000000 Pa 55°C 0.1 m
Contacts Usage:
standard contacts
Device Short Name:
XB4
Ik Degree Of Protection:
IK06 with keyhole cover ZBGP conforming to IEC 50102
Mechanical Durability:
1000000 cycles
Protective Treatment:
TH
Shape Of Screw Head:
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Terminals Description Iso N°1:
(23-24)NO || (13-14)NO
Contacts Type And Composition:
2 NO
[Ith] Conventional Free Air Thermal Current:
10 A EN/IEC 60947-5-1
Ambient Air Temperature For Storage:
-40-70°C
Electrical Durability:
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.2
Key Withdrawal Position:
in any position
Ambient Air Temperature For Operation:
-40-70°C
Product Or Component Type:
selector switch
Operator Profile:
black key switch
Device Presentation:
complete product
[Uimp] Rated Impulse Withstand Voltage:
6 kV EN 60947-1
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Overvoltage Category:
class I IEC 60536
Head Type:
standard
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Contact Operation:
slow-break
Short-Circuit Protection:
10 A cartridge fuse gG EN/IEC 60947-5-1
[Ui] Rated Insulation Voltage:
600 V 3)EN 60947-1
Shape Of Signaling Unit Head:
round
Type Of Keylock:
key 455
Product Certifications:
GL || UL || LROS (Lloyds register of shipping) || DNV || CSA || BV
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end EN/IEC 60947-1
Contact Block Material:
Metal
Includes Operator Key:
Key Included
Panel Cutout Diameter:
22 mm
Switch Function @ 2nd Position:
Off
Key Removal Position:
Any Position
Operator Head Color:
Black
Overall Depth:
3.39 in
Number of Positions:
3
Operator Head Type:
Keyed
Overall Height:
1.85 in
Hazardous Location Specification:
Not Rated
Switch Function @ 1st Position:
On
Manufacturer Warranty Length:
18 mo
Switch Function @ 3rd Position:
On
Switch Function @ 4th Position:
No Fourth Position
Overall Width:
1.18 in
Lamp Voltage - Maximum:
Not Applicable
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 4, 4X
Operator Illumination:
Non-Illuminated
Package Quantity:
1
